I/O Map; Table 3: I/O Map - ADLINK Technology AmITX-CF-I User Manual

Hex Range
FD6F0000-FDFFFFFF
FE000000-FE01FFFF
FE010000-FE010FFF
FE200000-FE7FFFFF
FED00000-FED003FF
FED10000-FED17FFF
FED18000-FED18FFF
FED19000-FED19FFF
FED20000-FED3FFFF
FED45000-FED8FFFF
FED90000-FED93FFF
FED90000-FED93FFF
FEE00000-FEEFFFFF
FF000000-FFFFFFFF
6.2

I/O Map

Table 3: I/O Map

Hex Range Device
0000-0C7F PCI Express Root Complex
0020-0021 Programmable interrupt controller
0024-0025 Programmable interrupt controller
0028-0029 Programmable interrupt controller
002C-002D Programmable interrupt controller
002E-002F Motherboard Resources
0030-0031 Programmable interrupt controller
0034-0035 Programmable interrupt controller
0038-0039 Programmable interrupt controller
003C-003D Programmable interrupt controller
0040-0043 System Timer
004E-004F Motherboard Resources
0050-0053 System Timer
0061-0061 Motherboard Resources
0063-0063 Motherboard Resources
0065-0065 Motherboard Resources
32
Device
Mother resources
Mother resources
Intel SPI Controller
Mother resources
High precision event timer
Mother resources
Mother resources
Mother resources
Mother resources
Mother resources
Mother resources
Mother resources
Mother resources
Mother resources
System Resources
