7.4.2 PCH IO Configuration
Feature
PCH-IO Configuration
PCI Express Configuration
SATA And RST
Configuration
USB Configuration
HD Audio Configuration
LAN1 Controller
LAN1 PXE OpROM
LAN2 Controller
LAN O PXE OpROM
Restore AC Power Loss
GPIO Group Control
GPIO 1 Control
GPIO 2 Control
GPIO 3 Control
GPIO 4 Control
GPIO 5 Control
GPIO 6 Control
GPIO 7 Control
GPIO 8 Control
BIOS Setup
Options
Disabled
Enabled
Enabled
Disabled
Disabled
Enabled
Enabled
Disabled
Power On
Power Off
Last State
Enabled
Disabled
Input
Output High
Output Low
Input
Output High
Output Low
Input
Output High
Output Low
Input
Output High
Output Low
Input
Output High
Output Low
Input
Output High
Output Low
Input
Output High
Output Low
Input
Output High
Output Low
Description
PCI Express Configuration settings.
SATA Device Options Setting.
USB Configuration settings.
HD Audio Subsystem Configuration Settings.
Control the PCI Express Root Port.
Enable or disable boot option for LAN1 Controller.
Control the PCI Express Root Port.
Enable or disable boot option for LAN2 Controller.
Specify what state to go to when power is re-
applied after a power failure (G3 state).
Configure the digital GPIO pins.
Configure Digital I/O Pin.
Configure Digital I/O Pin.
Configure Digital I/O Pin.
Configure Digital I/O Pin.
Configure Digital I/O Pin.
Configure Digital I/O Pin.
Configure Digital I/O Pin.
Configure Digital I/O Pin.
AmITX-CF-I
51
