LCD Control
Feature
LCD Control
LVDS Control
LVDS Panel Type
LVDS Brightness Control
LVDS Back Light PWM
Frequency
7.4.1.3 PEG Port Configuration
Feature
PEG Port Configuration
PEG 0:1:0
Enable Root Port
Max Link Speed
PEG0 Hotplug
Extra Bus Reserved
Reserved Memory
Reserved I/O
Detect Non-Compliance
Device
50
Options
Enabled
Disabled
640x480@60Hz 18bits Single
800x480@60Hz 18bits Single
800x600@60Hz 18bits Single
1024x768@60Hz 18bits Single
1280x1024@60Hz 24bits Dual
1366x768@60Hz 18bits Single
1440x900@60Hz 24bits Dual
1680x1050@60Hz 24bits Dual
1920x1080@60Hz 24bits Dual
1920x1200@60Hz 24bits Dual
255
200 Hz
250 Hz
333 Hz
500 Hz
1K Hz
11.6K Hz
15.6K Hz
23.3K Hz
Options
Not Present
Disabled
Enabled
Auto
Auto
Gen1
Gen2
Gen3
Disabled
Enabled
0
10
4
Disabled
Enabled
Description
Enable/Disable LVDS.
Select LCD Panel Type.
Adjust Brightness of LVDS (from 1~225).
Adjust LVDS Back Light PWM Frequency.
Description
Enable or Disable the Root Port.
Configure PEG 0:1:0 Max Speed.
Enable or Disable PCI Express hot plugging.
Extra bus reserved (0-7) for bridges behind this
Root Bridge
Reserved Memory for this Root Bridge.
Reserved I/O (4K/8K/12K/16K/20K) Range for this
Root Bridge
Detect Non-Compliance PCI Express Device in
PEG.
BIOS Setup
