7.3.7.1 Console Redirection Settings
Feature
COM1
Console Redirection
Settings
Terminal Type
Bits per second
Data Bits
Parity
Stop Bits
Flow Control
VT-UTF8 Combo Key
Support
Recorder Mode
Resolution 100x31
Putty KeyPad
BIOS Setup
Options
VT100
VT100+
VT-UTF8
ANSI
9600
19200
38400
57600
115200
7
8
None
Even
Odd
Mark
Space
1
2
None
Hardware RTS/CTS
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
VT100
LINUX
XTERMR6
SCO
ESCN
VT400
Description
Emulation: ANSI: Extended ASCII char set.
VT100: ASCII char set. VT100+: Extends VT100
to support color, function keys, etc. VT-UTF8:
Uses UTF8 encoding to map Unicode chars onto
1 or more bytes.
Selects serial port transmission speed. The speed
must be matched on the other side. Long or noisy
lines may require lower speeds.
Data Bits.
A parity bit can be sent with the data bits to detect
some transmission errors.
Stop bits indicate the end of a serial data packet.
Flow control can prevent data loss from buffer
overflow.
Enable VT-UTF8 Combination Key Support for
ANSI/VT100 terminals.
With the mode enabled only text will be sent. This
is to capture Terminal data.
Enables or disables extended terminal resolution.
Select FunctionKey and KeyPad on Putty.
