CC2652PSIP SimpleLink™ Multiprotocol 2.4-GHz Wireless System-in-Package

1 Features

Wireless microcontroller
• Powerful 48-MHz Arm® Cortex®-M4F processor
• 352KB flash program memory
• 256KB of ROM for protocols and library functions
• 8KB of cache SRAM
• 80KB of ultra-low leakage SRAM with parity for
high-reliability operation
• Dynamic multiprotocol manager (DMM) driver
• Programmable radio includes support for 2-
(G)FSK, 4-(G)FSK, MSK, OOK, Bluetooth® 5.2
Low Energy, IEEE 802.15.4 PHY and MAC
• Supports over-the-air upgrade (OTA)
Ultra-low power sensor controller
• Autonomous MCU with 4KB of SRAM
• Sample, store, and process sensor data
• Fast wake-up for low-power operation
• Software defined peripherals; capacitive touch,
flow meter, LCD
Low power consumption
• MCU consumption:
– 3.5 mA active mode, CoreMark
– 74 μA/MHz running CoreMark
– 1 μA standby mode, RTC, 80KB RAM
– 160 nA shutdown mode, wake-up on pin
• Ultra low-power sensor controller consumption:
– 30.1 μA in 2 MHz mode
– 808 μA in 24 MHz mode
• Radio Consumption:
– 7.3 mA RX at 2.4 GHz
– 7.9 mA TX at 0 dBm
– 10.9 mA TX at +5 dBm
– 33 mA TX at +10 dBm
Wireless protocol support
• Thread, Zigbee®, Matter
• Bluetooth® 5.2 Low Energy
• SimpleLink™ TI 15.4-stack
• Proprietary systems
High performance radio
• -103 dBm sensitivity for Bluetooth® Low Energy
125-kbps LE Coded PHY
• Output power up to +10 dBm with temperature
compensation
An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,
intellectual property matters and other important disclaimers. PRODUCTION DATA.
With Integrated Power Amplifier
Regulatory compliance
•
MCU peripherals
•
•
•
•
•
•
•
•
•
Security enablers
•
•
•
•
Development tools and software
•
•
•
•
•
Operating range
•
•
•
Package
•
•
SWRS263A – FEBRUARY 2021 – REVISED JUNE 2022
Regulatory certification for compliance with
worldwide radio frequency:
– ETSI RED (Europe)
– ISED (Canada)
– FCC (USA)
Digital peripherals can be routed to any of 30
GPIOs
Four 32-bit or eight 16-bit general-purpose timers
12-bit ADC, 200 kSamples/s, 8 channels
8-bit DAC
Two comparators
Programmable current source
2
Two UART, two SSI, I C, I
Real-time clock (RTC)
Integrated temperature and battery monitor
AES 128- and 256-bit cryptographic accelerator
ECC and RSA public key hardware accelerator
SHA2 Accelerator (full suite up to SHA-512)
True random number generator (TRNG)
LP-CC2652RSIP Development Kit
SimpleLink™ CC13xx and CC26xx Software
Development Kit (SDK)
SmartRF™ Studio for simple radio configuration
Sensor Controller Studio for building low-power
sensing applications
SysConfig system configuration tool
On-chip buck DC/DC converter
1.8-V to 3.8-V single supply voltage
T : -40 to +105°C
j
7-mm × 7-mm MOT (30 GPIOs)
RoHS-compliant package
CC2652PSIP
2
S
