iQ200 User's Manual
LED Indicator
[READY]
[MEDIA]
WIFI
Panel Buttons
The three buttons on the front of the printer, please refer to Table 3-2 below for details regarding
their functionality.
Buttons
[PAUSE/Self Test]
[FEED/Calibration] When printer is in a standby state,
[CANCEL/Reset]
Table 3-1 LED Indicator Description
• If the indicator is on, the printer is ready and waiting for user input
• If only the [READY] indicator is blinking, then the printer is
paused and awaiting further instruction
• If the indicator is on, it means the printer is at a normal working
state
• If both the [READY] and [MEDIA] indicators are blinking, then
the printer detected media out
• If the indicator is on, it indicates the Wi-Fi is connected
• If the indicator is off, it indicates the Wi-Fi function is disabled
Table 3-2 Panel Button Description
Basic Functions
• When printer is in working or
standby state, press once to
pause the printer
• When printer is in a paused
state, press once to resume
press once and the printer would
feed one label
When printer is in an error state,
press once to clear the error report
Chapter 3: Operations and Settings
Description
Advanced Functions
(Press and hold for 4 seconds)
Self-test:
The printer performs a self-test and
prints out a configuration report
Media Calibration
Reset:
Resets the printer to Factory Default
Settings
21
