Figure 2-20 End-fixing Tape Position
Chapter 2: Setup and Use
Tape
The tape shall avoid
covering the hole
Tape
The position of the
tape should be made
known to user to
avoid positioning
Media Sensors over
the tape area.
Tape
The position of the
tape should be made
known to user to
avoid positioning
Media Sensors over
the tape area.
Tape
The tape shall avoid
covering the black mark
