1.1 Applications

•
Interface to high-speed peripherals
•
High-speed data transfers from other computers
•
Automated test equipment (ATE)
•
Electronic and logic testing
•
Interface to external high-speed A/D and D/A converter
•
Digital pattern generator
•
Waveform and pulse generation
•
Parallel digital communication

1.2 Features

The PCI-7300A Ultra-High Speed DIO card provides the following advanced
features:
•
32 digital input/output channels
•
Extra 4-bit TTL digital input and output channels
•
Transfer up to 80M Bytes per second
•
SCSI active terminator for high speed and long distance data transfer
•
32-bit PCI bus
•
Plug and Play
•
Scatter/gatter DMA
•
On-board internal clock generator
•
Internal timer/external clock controls input sampling rate
•
Internal timer control digital output rate
•
ACK and REQ for handshaking
•
TRIG signal controls start of data acquisition/pattern generation
•
On-board 64KB FIFO
•
100-pin SCSI style connector
