DI_FIFO_CLR (R/W)
0: No effect
1: Clear digital input FIFO. If both PORTA and PORTB are configured as
inputs, both FIFO will be cleared. Always get 0 when read.
DI_OVER (R/W)
0: DI FIFO does not full during input sampling
1: DI FIFO full during input sampling, some input data was lost,
write "1" to clear this bit
DI_FIFO_FULL (RO)
0: DI FIFO is not full
1: DI FIFO is full
DI_FIFO_EMPTY (RO)
0: DI FIFO is not empty
1: DI FIFO is empty
3.3 DO_CSR: DO Control & Status Register
Digital input control and status checking is done by this register.
Address: BASE + 04
Attribute: READ/WRITE
Data Format:
Bit # 3~0
Bit # 7~4
PG_STOP_TRIG
Bit # 11~8
DO_FIFO_FULL
Bit # 15~12
Bit # 31~16
Don't Cared
(2) This bit is different between Rev.A and Rev.B.
DO_32 (R/W)
0: Output port is not 32-bit wide ( 16-bit or 8-bit wide)
1: Output port is 32-bit wide, PORTA is configured as the extension of PORTB.
That means PORTB is output lines (0...15), and PORTA is output lines
(16...31). All PORTA control signals are disabled.
DO_MODE (R/W)
00: use timer1 output as output clock
01: use 20MHz clock as output clock
10: use 10MHz clock as output clock
11: REQ/ACK handshaking mode
DO_WAIT_NAE
PB_TERM_OFF
-
DO_MODE
DO_UNDER
- BURST_HNDSH (2)
DO_WAIT_TRG
DO_FIFO_CLR
Registers • 19
DO_32
PAT_GEN
DO_EN
DO_FIFO_EMPTY
