2
Installation
This chapter describes how to install the cPCI/PCI-7300A. At first, the contents
in the package and unpacking information that you should be careful are
described. Because the PCI-7300A is following the PCI design philosophy, it
is no more jumpers and DIP switches setting for configuration. The Interrupt
and I/O port address are the variables associated with automatic configuration,
the resource allocation is managed by the system BIOS. Upon system
power-on, the internal configuration registers on the board interact with the
BIOS.
2.1 What You Have
In addition to this User's Manual, the package includes the following items:
•
cPCI/PCI-7300A 80MB Ultra-High Speed 32-CH Digital I/O Card
•
ADLINK All-in-one CD
•
Software Installation Guide
If any of these items is missing or damaged, contact the dealer from whom you
purchased the product. Save the shipping materials and carton in case you
want to ship or store the product in the future.
Installation • 7
