Protection Setup
92 S&C Instruction Sheet 766-530
Reset Time—When the Definite Time reset mode is selected, enter the time delay for
the reset (in seconds). (Range: 0.000-6000.000; Step: 0.001)
Definite Time 1 Min. Trip—This is the current (in primary amperes) at which the
Definite Time 1 element picks up. (Range: 3-16,000; Step: 1) The stated maximum
is for 15-kV IntelliRupter fault interrupters; 27-kV and 38-kV models are limited to
12,500 amps maximum.
Definite Time 1 Min. Time—This is the time delay (in seconds) after which the
Definite Time 1 element trips. (Range: 1.000-6000.000; Step: 0.001)
Definite Time 2 Min. Trip—This is the current (in primary amperes) at which the
Definite Time 2 element picks up. (Range: 3-16,000; Step: 1) The stated maximum
is for 15-kV IntelliRupter fault interrupters; 27-kV and 38-kV models are limited to
12,500 amps maximum.
Definite Time 2 Min. Time—This is the time delay (in seconds) after which the
Definite Time 2 element trips. (Range: 1.000-600.000; Step: 0.001)
Ground Trip Block Radio Buttons
When the Allow Ground Trip Block mode is active (the default), the Ground Trip
element blocks commands from SCADA and IntelliLink software, and the manual
GROUND TRIP BLOCK lever will operate normally. The Ground Trip element will be
blocked even in the Hot Line Tag profile.
When the Do not allow Ground Trip Block setting is active, the Ground
element will be implemented as configured for the Hot Line Tag profile, overriding any
Ground Trip Block commands from SCADA, IntelliLink software, or a manual GROUND
TRIP BLOCK lever operation. This override only applies to the Hot Line Tag profile.
