Restoration—External Device
142 S&C Instruction Sheet 766-530
Enable Remote Transmit from SCADA P.R.
Enabling this option will send a Prohibit Restoration command to all devices in the
list if any the following events are active: Hot Line Tag mode, Frequency Trip mode,
Manual Operation state, or Prohibit Restoration state is activated from a SCADA
command from a configured master station address.
Remotely Clear Prohibit Restoration
Clicking on this button sends a Clear Prohibit Restoration command to the local device
and all devices in the list and will clear the local Prohibit Restoration state. If an event
is still active (Hot Line Tag mode, Frequency Trip mode, Manual Operation state),
the Clear Prohibit Restoration command will not be sent.
Remote Transfer Trip List Section
Transfer Trip commands are sent from the device to distributed generation resources
within the distribution system immediately upon detection of a circuit anomaly so the
distributed generation does not interfere with IntelliTeam system restoration activities.
This action is both for safety reasons and for the protection of load.
If the local device trips open due to a Protection or Automatic Sectionalizing event,
and the Transfer Trip feature is enabled, it sends Transfer Trip commands to all
devices, whether S&C controls or third party controls, listed on its Remote Transfer
Trip List. The Transfer Trip commands are sent, no matter what state the DG/DER is
in at the time, to ensure it is disconnected from the system. When the trip is due to a
Protection event, the Transfer Trip commands will initiate following the initial trip.
Lockout state is not necessary.
Device
This is the Device ID for the remote device.
RTU Address
Enter the address of the remote device. (Range: 0-65519; Step: 1; Default: 0 (Not
Configured))
Port Code
Select the port to use for transmitting to the remote device. (Default: UDP)
IP Address
When the Port Code is set to "UDP," enter the IP address of the remote device here.
Retry Count
Enter the number of retries to perform on any timeout event. (Range: 0-255; Step: 1;
Default: 1)
Retry Timer
Enter the amount of time in seconds to wait before a retry is attempted. (Range: 0-255;
Step: 1; Default: 5)
