Intellirupter ® Fault Interrupter Software; Requirements And Installation; Assistant - S&C IntelliRupter PulseCloser Manual

Requirements and
Installation
Coordinaide™—
The S&C Protection
& Coordination

Assistant

Review the "Computer Requirements" and "Software Installation" sections in
Instr uction Sheet 766 - 571, "IntelliRupter® PulseCloser® Fault Inter r upter:
Software Installation."
Install and use only the IntelliLink Setup Software supplied for IntelliRupter fault
interrupter . IntelliLink Setup Software furnished with other S&C products cannot be
used to access an IntelliRupter fault interrupter .
A remote or local upgrade puts a control into the Prohibit Restoration state . When
upgrading controls in an IntelliTeam SG system, use the following procedure:
STEP 1. Upgrade the control software . This can be done with IntelliLink Setup
Software .
STEP 2. After the upgrade, verify all settings were preserved .
STEP 3. Use IntelliTeam Designer Version 6 .0 .x .x to re-push IntelliTeam SG system
configurations to all FeederNets that have updated devices .
STEP 4. If a device is an open point, push the configuration to both FeederNets for
that device .
STEP 5. Verify the team configurations .
For IntelliNode™ Interface Modules only, set the External Device Data
STEP 6.
Updated mode to the Running setting .
Enable the Automatic Restoration mode on all upgraded controls .
STEP 7.
Coordinaide software can plot various TCC curves for a protection overcurrent element
direction. The curves appropriate for both the upstream and downstream protective
devices can then be selected, and their parameters downloaded to a Setpoints Group File
for uploading to the IntelliRupter fault interrupter control. A Setpoints Group File can
also be downloaded from a control and opened using Coordinaide software for evaluation.
T he l i n k t o Coord i n a ide sof t wa re i s loc a t ed on t he S &C web sit e a t:
sandc.com/en/support/coordinaide/. When selected, the link the opening page has a
brief description of the protection applications Coordinaide software can handle. When
launching the program, the next page contains the Conditions of Use disclaimer, the
minimum Web browser requirements, and a link to the Coordinaide software users guide.
After agreeing to the Conditions of Use, one final click launches the program.
IntelliRupter Fault Interrupter Software
®
NOTICE
NOTICE
S&C Instruction Sheet 766-530 9
