FSV-25 MARK-2/FSV-25S MARK-2
Model
SAFETY INSTRUCTIONS ........................i
SYSTEM CONFIGURATION ..................iii
EQUIPMENT LISTS................................iv
1.1 Hull Unit ..............................................1-1
1.2 Processor Unit ....................................1-6
1.3 Control Unit .........................................1-7
1.4 Transceiver Unit................................1-12
1.5 Power Supply Unit ............................1-14
1.6 Junction Box .....................................1-15
1.7 Raise/Lower Control Box ..................1-16
1.8 Control Box Extension Box ...............1-17
Tank ..................................................1-18
1.10 Sub Control Unit (Option)..................1-22
2. WIRING............................................2-1
2.1 How to Connect the Units ...................2-1
2.2 Processor Unit ....................................2-4
2.3 Control Unit .......................................2-10
2.4 Transceiver Unit................................2-11
2.5 Junction Box .....................................2-14
2.6 Raise/Lower Control Box ..................2-15
2.7 Power Supply Unit ............................2-16
2.8 Control Box Extension Box ...............2-17
3.1 How to Set the Language ...................3-1
Position ...............................................3-2
3.3 Hull Unit Checks .................................3-3
3.4 How to Adjust the Heading .................3-9
10
3.8 System Menu ....................................3-11
Professional ......................................3-13
All brand and product names are trademarks, registered trademarks or service marks of their respective holders.
COLOR SCANNING SONAR
www.furuno.com
Installation Manual
APPX. 1 JIS CABLE GUIDE............AP-1
APPX. 2 FRP/ALUMINUM
INSTALLATION ................AP-2
APPX. 3 INSTALLATION CHECK
LIST ...................................AP-5
PACKING LIST(S)............................... A-1
OUTLINE DRAWING(S)...................... D-1
INTERCONNECTION DIAGRAM(S) ... S-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FSV-25 MARK-2 and is the answer not in the manual?

Questions and answers

Related Manuals for Furuno FSV-25 MARK-2

Summary of Contents for Furuno FSV-25 MARK-2

  • Page 1: Table Of Contents

    Installation Manual COLOR SCANNING SONAR FSV-25 MARK-2/FSV-25S MARK-2 Model SAFETY INSTRUCTIONS ......i APPX. 1 JIS CABLE GUIDE....AP-1 SYSTEM CONFIGURATION ....iii APPX. 2 FRP/ALUMINUM RETRACTION TANK EQUIPMENT LISTS........iv INSTALLATION ....AP-2 APPX. 3 INSTALLATION CHECK 1. HOW TO INSTALL THE SYSTEM ..1-1 LIST ........AP-5...
  • Page 2 The paper used in this manual is elemental chlorine free. ・FURUNO Authorized Distributor/Dealer 9-52 Ashihara-cho, Nishinomiya, 662-8580, JAPAN A : JAN 2022 Printed in Japan All rights reserved. Pub. No. IME-13690-A (REFU ) FSV-25-MARK-2 0 0 0 1 9 9 2 4 5 1 1...

  • Page 3: Safety Instructions

    Fire, electrical shock or serious injury can FURUNO will assume no responsibility for result if the power is left on or is applied any damage associated with improper while the equipment is being installed.
  • Page 4 SAFETY INSTRUCTIONS CAUTION DANGER Maximum speed while the transducer is Install the specified transducer tank in projected or being raised or lowered is accordance with the installation as below, to prevent damage to the instructions. If a different tank is to be transducer.

  • Page 5: System Configuration

    Control Unit FSV-8501-MK-2 REMOTE CONTROLLER REMOTE CONTROLLER Gyro Compass (AD-100) Processor Unit NMEA0183 devices (max. five units) FSV-2503-MK2 (FSV-25 MARK-2)/ External KP FSV-2503S-MK2 USB 3.0 devices (max. two units) (FSV-25S MARK-2) Sub Control Unit USB 2.0 devices (max. two units) FSV-853...

  • Page 6: Equipment Lists

    EQUIPMENT LISTS Standard supply Name Type Code No. Remarks Control Unit FSV-8501-MK2 Cable length: 10 m Processor Unit FSV-2503-MK2 For FSV-25 MARK-2 FSV-2503S-MK2 For FSV-25S MARK-2 Transceiver Unit FSV-251-MK2 Power Supply FSV-252 Unit Junction Box FSV-2550-MK2 Hull Unit FSV-253-MK2 1200 mm travel...
  • Page 7 EQUIPMENT LISTS Optional supply Name Type Code No. Remarks Control Unit FSV-8501-MK2 Remote Controller FSV-854-MK2 Sub Control Unit FSV-853 Control Box Exten- FSV-2560 For remote installation of raise/ sion Box lower control box AC/DC Power Sup- PR-241 ply Unit External Loudspeak- SEM-21Q Retraction Tank OP10-40...
  • Page 8 EQUIPMENT LISTS This page is intentionally left blank.

  • Page 9: How To Install The System

    HOW TO INSTALL THE SYSTEM Hull Unit Note 1: The raise/lower control box on the hull unit contains a inertial measurement unit. Handle the unit carefully. Note 2: Handle the transducer carefully. Rough handling can damage its sensitive components. 1.1.1 Installation considerations Decide the location of the hull unit through consultation with the dockyard and ship owner.
  • Page 10 1. HOW TO INSTALL THE SYSTEM Note 1: After you install the hull unit, make sure you install anti-vibration stays. 1300 mm 650 mm (See "How to install the stays (anti-vibra- tion and anti-shock measures)" on page 1-5.) Note 2: Prepare a secure and firm safety fence for the hull unit, to prevent acciden- tal injury from the moving hull unit.
  • Page 11 1. HOW TO INSTALL THE SYSTEM • If there is no suitable location where the hull frame and keel intersect, install suitable “T” shaped reinforcement ribs, then weld the base of the frame to the reinforcement ribs and the sides of the reinforcement ribs to the hull walls or other nearby reinforcement ribs.
  • Page 12 1. HOW TO INSTALL THE SYSTEM 2. Apply lithium grease to the O-ring and O-ring groove. Place the O-ring in its groove on the tank flange. 3. Orient the hull unit so that the bow mark (inscribed) on its flange points toward the ship's bow.

  • Page 13: Hull Unit

    1. HOW TO INSTALL THE SYSTEM How to install the stays (anti-vibration and anti-shock measures) This measure must be done after installing the hull unit to prevent damage from vibration or impact shock to the transducer. Stays should be as sturdy as possible (75759 mm minimum recommended).

  • Page 14: Processor Unit

    1. HOW TO INSTALL THE SYSTEM Processor Unit The processor unit can be installed on a deck or bulkhead. Mounting considerations Select a mounting location, keeping in mind the following points: • Locate the unit out of direct sunlight and away from heat sources. •...

  • Page 15: Control Unit

    1. HOW TO INSTALL THE SYSTEM 1.2.2 Bulkhead mount 1. Drill four pilot holes in the mounting location for mounting screws (M6 bolts or coach screws 6), referring to the outline drawing at the back of this manual. 2. Screw two mounting screws (supplied locally) into the lower pilot holes. Leave 5 mm of thread visible.
  • Page 16 1. HOW TO INSTALL THE SYSTEM 1.3.1 Tabletop mounting without KB fixture 1. Drill four pilot holes in the mounting location for stud bolts (M450), referring to the outline drawing at the back of this manual. 2. Attach a ground wire (IV-1.25sq, supplied locally) to the ground terminal at the bottom of the unit, then connect the other end of the ground wire with the ship’s ground.
  • Page 17 1. HOW TO INSTALL THE SYSTEM 5. Fasten the four wing nuts (supplied) to the stud bolts from the rear side of the mounting surface. Wing nut (4 pcs) 1.3.2 Tabletop mounting with KB fixture The control unit can be mounted with the KB fixture, which mounts the unit at an angle. 1.
  • Page 18 1. HOW TO INSTALL THE SYSTEM 3. Attach a ground wire (IV-1.25sq, supplied locally) to the ground terminal at the bottom of the unit, then connect the other end of the ground wire with the ship’s ground. Ground screw* Ground wire : Use the screw that is preattached to the ground terminal.
  • Page 19 1. HOW TO INSTALL THE SYSTEM 1.3.3 Flush mounting Note: Be sure the mounting surface is flat. 1. Referring to the outline drawing at the back of this manual, prepare a cutout, then drill four pilot holes in the mounting location. 2.

  • Page 20: Transceiver Unit

    1. HOW TO INSTALL THE SYSTEM Transceiver Unit Select a mounting location considering that the effective length of the cable between the transceiver unit and the hull unit is 5 m, 10 m or 20m. The transceiver unit should be fixed to a mounting base (shipyard supply) whose dimensions are as shown in the outline drawing at the back of this manual.
  • Page 21 1. HOW TO INSTALL THE SYSTEM 3. Fix the transceiver unit to the anti-vi- bration devices with M1250 hex Nut (M12, 2 pcs) bolts, spring washers, plain washers and 2  nuts (supplied). Insert the Spring washer, Flat washer bolts from the bottom of the fixing (M12) plate.

  • Page 22: Power Supply Unit

    1. HOW TO INSTALL THE SYSTEM 3) Adjust the rope length to allow the transducer unit to sway forward and back- ward. Push, or pull, the transceiver unit so that the stoppers on the anti-vibra- tion device meet, then tighten the rope. Behind rope Fixture (no slack)

  • Page 23: Junction Box

    1. HOW TO INSTALL THE SYSTEM Suspending the FSV-252 (when using a crane, etc.) The FSV-252 weighs approximately 37.5 kg. The attached eye-bolts are used when hanging the FSV-252. Only suspend the FSV-252 upside down when moving it, do not install the FSV-252 upside down.

  • Page 24: Raise/Lower Control Box

    1. HOW TO INSTALL THE SYSTEM Raise/Lower Control Box The inertial measurement unit is installed in the raise/lower control box. When using the control box extension box (FSV-2560), remove the inertial measurement unit and two fans from the raise/lower control box and install them in the control box extension box, then secure the control box extension box to the hull unit.

  • Page 25: Control Box Extension Box

    1. HOW TO INSTALL THE SYSTEM Control Box Extension Box To install the optional control box extension box, do the following. 1. Unfasten the M10 bolts (4 pcs.) connecting the raise/lower control box to the hull unit. 2. Disconnect the raise/lower control box cabling, then connect the cables to the control box extension box.

  • Page 26: Installing To An Existing Retraction Tank

    1. HOW TO INSTALL THE SYSTEM Installing to an Existing Retraction Tank To install the hull unit to the existing retraction tank for the CSH-20 or FSV-24/30/35 hull unit on a steel hull, use the following optional kit. • When tank length does not need to be extended, use the attachment kit. •...
  • Page 27 1. HOW TO INSTALL THE SYSTEM 4. Coat threads of the bolts with a slight amount of lithium grease to prevent scorch- ing, then secure the and hull unit, referring to the following figure. Hex nut Spring washer Flat washer Stern O-ring O-ring...
  • Page 28 1. HOW TO INSTALL THE SYSTEM 1.9.2 When tank extension is required If you need to extend to the tank length when installing to an existing retraction tank, use the optional attachment kit and attachment flange. Select the correct attachment flange from the following table, using the length of the pre-installed tank to determine the raising height.
  • Page 29 1. HOW TO INSTALL THE SYSTEM 4. Coat threads of the bolts with a slight amount of lithium grease to prevent scorch- ing, then secure the attachment flange and hull unit, referring to the following fig- ure. Stern side (7 places) is secured using stud Bow side (17 places) bolts, flat washers, spring washers and 2 ×...

  • Page 30: Sub Control Unit (Option)

    1. HOW TO INSTALL THE SYSTEM 1.10 Sub Control Unit (Option) The control unit has following three mounting methods: • Tabletop mounting: The unit is secured from the underside. • Tabletop mounting with KB fixture: The unit is secured from the topside. •...
  • Page 31 1. HOW TO INSTALL THE SYSTEM 1.10.2 Desktop installation, no keyboard fixture 1. Drill four mounting holes of 5 mm diameter, referring to the outline drawing at the back of this manual. 2. Fix the unit with four screws (M4, supplied locally) from under side of the desktop. Supply the screws locally.
  • Page 32 1. HOW TO INSTALL THE SYSTEM This page is intentionally left blank. 1-24...

  • Page 33: Wiring

    TT(P)YCSLA-1Q Gyro Compass (AD-100) TT(P)YCSLA-1Q 10 m NMEA0183 devices (max. five units) Processor Unit FSV-2503-MK2 TT(P)YCSLA-1 External KP (FSV-25 MARK-2)/ 5/10 m USB3.0 FSV-2503S-MK2 USB 3.0 devices (max. two units) MJ-A3SPF0018-050ZC, 5 m (FSV-25S MARK-2) USB2.0 12-24 VDC USB 2.0 devices (max. two units)
  • Page 34 2. WIRING Grounding The processor unit, transceiver unit, power supply unit and hull unit must have a pro- tective earth. Use a ground wire (IV-8sq., local supply) or a ground plate. A copper strap is supplied with the transceiver unit, power supply unit and raise/lower control box.
  • Page 35 2. WIRING • When the transducer is removed from the hull unit while installing the hull unit, re- attach the transducer and route the transducer cables as shown in the following fig- ure. Transducer cable routing layout Cable tie (CV-550B, 2 pcs) Inside Outside Cable clamp (2 pcs)
  • Page 36 2. WIRING Processor Unit 2.2.1 Connectors USB1 USB3.0 USB3 USB2.0 HDMI1 To Monitor Unit (Main) USB cable Cable entrance HDMI2 To Monitor Unit (Sub) HDMI-TO-DVI-L, 5.3/10.3 m USB cable SPEAKER LAN2 IV-8sq. To Speaker Not used. USB4 (SEM-21Q) DTIC5E350SLABVCVxxT USB2.0 MJ-A3SPF0018-050ZC, USB2 Max 100 m...
  • Page 37 2. WIRING 2.2.2 Internal wiring and cable clamp position Terminal opener Secure each cable to the wiring clamp. Fasten the crimp-on lug (drain wire) of the TT(P)YCSLA cable. Cable clamp 8 9 10 5 11 12 Clamp position Connect to Cable from Cable NMEA0183 equipment...
  • Page 38 2. WIRING 2.2.3 Cable fabrication 10S2380 cable Note: For how to fabricate the cable end at the transceiver unit side, see section 2.4.1. Processor Unit side Outer sheath Armor Inner sheath Shield 35 35 Vinyl tape Vinyl tape Cores 6 mm Clamp here.
  • Page 39 2. WIRING LAN cable Fabricate the LAN cable (DTIC5E350SLABVCVxxT, max 100 m), referring to the fol- lowing figure. After fabricating the cable, attach the modular connector. Note: This equipment only uses straight cables. Use a CAT5E LAN cable. Processor Unit side Armor Cable jacket 40 40...
  • Page 40 2. WIRING TT(P)YCSLA cable 495 mm 495 mm 450 mm 450 mm Drain wire Drain wire 6 mm 6 mm Armor Inner sheath 80 mm 80 mm Pass a heat shrinkable tube (supplied locally) onto the drain wire. 6 mm 6 mm Vinyl tape Attach a crimp-on lug (FV1.25-3,...

  • Page 41: Processor Unit

    2. WIRING 2.2.5 External switch connection External switches can be connected to the TB1 terminal in the processor unit to pro- vide one-touch access to a desired menu item or menu. Up to four external switches, each with an individual function, can be connected. Use a push button switch (momentary contact) for the external switch.

  • Page 42: Control Unit

    2. WIRING KP output To output the KP signal from the transceiver unit to external equipment, make the con- nection as follows: • When the external equipment is a current drive circuit: Use the TB8-5 and TB8-6. • When the external equipment is a voltage drive circuit: Use the TB8-7 and TB8-8. The signals for current and voltage drive circuit can be used simultaneously, for sep- arate destinations.

  • Page 43: Transceiver Unit

    2. WIRING Transceiver Unit Connect the cables, referring to the following figure. (40 pin) CN-B103 TRX-10 (64 pin) TRX-1 Secure cables CN-B101 inside cable clamp. CN-B102 Connector Secure shielded fitting section with steel clamps. Secure cables inside cable clamp. S10-20-10/20 (×...
  • Page 44 2. WIRING 2.4.1 How to connect the processor unit 10S2380 cable Fabricate the 10S2380 cable as shown in the following cable and pass the cable through the cable clamp on the transceiver unit, then connect to CN-B101. Transceiver Unit side 480 mm 480 mm 45 mm...
  • Page 45 2. WIRING 2.4.3 Power cable Fabricate the power cable (DPYCY-1.5) as shown in the following figure and connect the cable to TB-B101 of the transceiver unit. Cut the outer sheath and 140 mm 140 mm armor at the same location. 30 mm 30 mm Vinyl sheath...

  • Page 46: Junction Box

    2. WIRING Junction Box The junction box connects the transceiver unit to the hull unit using transducer cables (10CA10167, 10 pcs) from the transducer (hull unit) to the junction box and signal ca- bles (S10-20-5/10/20, 10 pcs) from the junction box to the transceiver unit. Connection Connect the transducer cables (10CA10167, 10 pcs) from the transducer and signal cables (S10-20-5/10/20, 10 pcs) from the transceiver unit to the JCTN1 to JCTN20...

  • Page 47: Raise/Lower Control Box

    2. WIRING Raise/Lower Control Box Connect the 3 phase power cable and the transceiver unit cables (10CA10053 - marked with “Control Unit”) as shown below. Cover the LSW HTX indicator using the supplied Blind Seal N2.5 (05-104-6519-0). Connect the transceiver Connect the transceiver cables (10CA10053) here.

  • Page 48: Power Supply Unit

    2. WIRING Cable clamp location Secure the cables in the cable clamp as shown in the following figure. Use a ground wire (IV-8 sq., local supply) to connect to the ship’s ground. 10CA10053 Transceiver unit (FSV-251-MK2) IV-8sq. Ship's ground Limit Limit Rotary Rotary...

  • Page 49: Control Box Extension Box

    2. WIRING The front panel of the power supply unit houses the Voltage breakers. Remove the protective sheet covering the breakers lid, then open the panel to adjust the breaker settings. • For 100/110/115V input set the double breaker on the right to ON.
  • Page 50 2. WIRING 2.8.1 Cable clamp location Secure all connected cabling in the cable clamp, referring to the following figure. Use a ground wire (IV-8 sq., local supply) to connect to the ship’s ground. Cables from raise/lower control box 10S10028 10S10029 10S10027 IV-8sq Ship's ground...
  • Page 51 2. WIRING 3. Disconnect the cable from the connector on the inertial measurement unit, then unfasten four screws to remove the unit. Inertial measurement unit Remove the cable from this connector. 4. Disconnect the fan connectors, then unfasten screws to remove two fans. Remove these connectors.
  • Page 52 2. WIRING 1. Unfasten six screws to remove the front Top cover cover. 2. Unfasten four screws to remove the top cover. Front cover Control box extension box 3. Install the fans in the control box extension box, using the four screws to secure them in place.
  • Page 53 2. WIRING 5. Unfasten four screws and set the inertial measurement unit, then fasten the screws to secure it. Inertial measurement unit Rear side: Inertial measurement unit Set the unit to the mounting screws, then fasten the screws. 6. Connect the D-SUB connector inside the control box extension box to the inertial measurement unit.
  • Page 54 2. WIRING This page is intentionally left blank. 2-22...

  • Page 55: Adjustment And Checks

    ADJUSTMENT AND CHECKS How to Set the Language This equipment is shipped with English set as the default language. To change the language in which the menus are displayed, follow the procedure below. The following languages are supported: English Spanish Korean Japanese Russian...

  • Page 56: How To Register The Transducer Position

    3. ADJUSTMENT AND CHECKS How to Register the Transducer Position To display the distance which the transducer is protruded, the limit switch location must be entered at the processor unit. To conduct this setting, the transducer must be at full protrusion. Also, confirm that the transducer is retracted before conducting this procedure.

  • Page 57: Hull Unit Checks

    3. ADJUSTMENT AND CHECKS Note: If transducer registration is aborted for any reason, the following message ap- pears. Left click [Quit] to close the message and restart the procedure once safety is ensured. TD position Registering Please register TD position, if safety is ensured. Quit Hull Unit Checks When performing maintenance to the hull unit and checking the movement, make sure...
  • Page 58 3. ADJUSTMENT AND CHECKS 3. Left click [Initial Settings]. The confirmation dialog pop-up window appears. 4. Left click [Changeable] in the pop-up window. Initial Setting Quit Language : English TVG Monitor Transp. : OFF Monitor Setting... Data Box... Mark Display... Mark Size...
  • Page 59 3. ADJUSTMENT AND CHECKS How to check the hull unit 1. Press the power key to turn the power on, then check that the LEDs located to the left of the power key and (Retract) key are turned on. 2. Confirm that the “3.3 V” and “UP” LEDs on control panel of the raise/lower control box are on.
  • Page 60 3. ADJUSTMENT AND CHECKS 6. Press the DOWN switch again to continue lowering. Confirm that the transducer stops at the mo- ment when the EMERGENCY STOP button is pressed. After you have confirmed the EMERGENCY STOP button stops the hull unit lowering, release the EMERGEN- CY STOP button by turning the EMERGENCY STOP button...
  • Page 61 3. ADJUSTMENT AND CHECKS 11. When the above tests are complete, switch the [TEST/NORMAL] switch back to [NORMAL] on the control panel. 12. On the control unit, press the (mid-protrusion) key and check that the hull unit is lowered to the half-way point. This must be done from a fully retracted position. While lowering, check that the LED on the left of the (mid-protrusion) key is flashing, the limiter makes a short beep sound and once the shaft stops at half-...
  • Page 62 3. ADJUSTMENT AND CHECKS 7 segment LED Display select button Changes the displayed figure 1. Encoder in the 7 segment LED in the 2. Fan revolutions following order, 1 - 2 - 3 - 4, 3. Roll angle 4. Pitch angle then returns to 1.

  • Page 63: How To Adjust The Heading

    3. ADJUSTMENT AND CHECKS How to Adjust the Heading Heading correction at the hull unit When the BOW mark on the flange of the hull unit can not be directed toward ship’s bow perfectly, adjust the heading so an echo which is dead ahead appears dead ahead on the display.

  • Page 64: How To Configure The Own Ship Mark

    3. ADJUSTMENT AND CHECKS How to Configure the Own Ship Mark Set your ship’s length and width and the position of the transducer, to accurately display the own ship mark on the screen. 1. Access the system menu, referring to section 3.8.1. 2.

  • Page 65: How To Set Up A Secondary Monitor.3-11

    3.8.1 How to access the system menu The system menu is used by FURUNO technicians to set up and maintain the unit. This menu should not be accessed otherwise. Use the following procedure to access the system menu items. (System menu items appear to the right of the regular menus.)
  • Page 66 3. ADJUSTMENT AND CHECKS 3.8.2 [Interface Setting] menu • [NMEA1 Baud Rate] to [NMEA5 Baud Rate]: Set the transmission rate for the NMEA1 to NMEA5 ports. (4800 bps, 9600 bps, 19200 bps, 38400 bps.) 3.8.3 [EXT Data Setting] menu • [Date&Time]: Select the input format for date and time data. (NONE, NMEA) •...

  • Page 67: Connection With Maxsea Tz Professional

    3. ADJUSTMENT AND CHECKS Connection with Maxsea TZ Professional Maxsea TZ Professional can display the sonar picture of this equipment and control some basic operation (range, tilt, gain control) of the sonar from the PC. To display the sonar picture in TZ Professional, connect the PC that TZ Professional is installed to the processor unit, via the LAN interface.
  • Page 68 3. ADJUSTMENT AND CHECKS This page is intentionally left blank. 3-14...

  • Page 69: Appx. 1 Jis Cable Guide

    EX: TTYCYSLA - 4 MPYC - 4 TTYCSLA-4 # of twisted pairs Designation type # of cores Designation type The following reference table lists gives the measurements of JIS cables commonly used with Furuno products: Cable Core Cable Core Diameter Type...
  • Page 70 • FURUNO does not supply any type of FRP/aluminum retraction tank. Keep in mind the structural integrity and waterproofing of the vessel when fabricating a FRP/ aluminum tank. FURUNO takes no responsibility for the fabrication or design of the FRP/alumi- num tank.

  • Page 71: Retraction Tank

    APPX. 2 FRP/ALUMINUM RETRACTION TANK INSTALLATION • When you install the hull unit to the existing retraction tank using the attachment flange (see section 1.9), be sure to reinforce the attachment flange using reinforcement ribs. if you cannot weld reinforcement ribs, install stays using the M20 bolt holes for securing the retraction tank and hull unit.
  • Page 72 APPX. 2 FRP/ALUMINUM RETRACTION TANK INSTALLATION 8. Insert the bolts with washers from the retraction tank flange, and then put one flat washer, one spring washer and one hex nut on each bolt. Fasten the hex nuts by hand. Leave one bolt hole empty (you should have one bolt, on spring washer, two flat washers and one hex nut remaining).
  • Page 73 APPX. 3 INSTALLATION CHECK LIST After completing the installation, perform the following checks: Check point Reference Result Hardware installation check O-ring in the retraction tank O-ring is attached to the retraction section 1.1.3 flange tank flange. O-ring in the attachment flange O-ring is attached to the attachment (when the attachment flange is flange.

  • Page 74: List

    APPX. 3 INSTALLATION CHECK LIST Check point Reference Result Function key setting Assign the function to the function Operator’s keys as necessary. manual Preset the horizontal mode Preset the horizontal mode ranges Operator’s ranges as selected with the RANGE control manual as necessary.
