For example:
Continuous mode, current level A =5A, width = 2mS. Current level B =10A, width =
3ms. Testing machine output voltage is 12V.
10A
5A
2.0ms
Continuous Transient Operation
Action
1. On the Function keypad, press
Shift
and
2. Press
WIDTH B=2mS, transition mode is CONTINOUS.
Shift
and
3. Press
Shift
and
4. Press

Pulse Transient Operation

In this mode, generates a transient pulse of programmable width when pulsed
transient operation is in effect.
For example: When load receiving one trigger signal, it will switch to 10A current value, and
taking 10mS to return the current value of 5A.
10A
5A
TWD
10ms
TRIG
Pulsed Transient Operation
Action
1. On the Function keypad, press
3.0ms
Input on/off
button to turn off the load input.
S-Tran
,
setting LEVEL A=5A, WIDTH A=3mS, LEVER B=10A,
Tran
to activate the transient mode.
Tran
again to stop the transient operation.
TWD
10ms
TRIG
Input on/off
button to turn off the load input.
.
41
