5.2.2 Pulse transient operation

Press (Shift)+ 2(Tran) enter the transient operation setup menu：
Steps
Press
1
move
press Enter to confirm.
Preess
transient operation mode as
2
PULSE(the indicator lamp Trig
will be lighted)
Set the rising slope, press
3
Enter to confirm
Set the descending slope,press
4
Enter to confirm
Set level A,press Enter to
5
confirm
Set level B,press Enter to
6
confirm
Set the time width,press Enter
7
to confirm
Open the transient test function,
8 mentain on the "on"selection ,
press Enter to confirm
Then the VFD will display
9 TRAN
Turn on the load,
10
press
trigger
Press anyone of CC/CV/CW/CR button will quit the transient test,if
11
you want to continue the test again,please repeat 1-10 steps.
Operation
(Shift)+ 2(Tran),
key to select ON.,
to select
and Trig
(Shift)+ (Trigger) to
VFD display
TRAN ON
MODE CONTINUOUS >
UP=1A/US
DOWN=2A/US
Level A=5.000A
Level B=10.000A
WIDTH=5S(0.00005-3600S)
TRAN ON
10.0000V 0.0000A
0.00W TRAN. 0
Trig
45
