Transition Testing Operation
Users could switch between the two different current and voltage in the transition
mode; it could test the transition specialty of power supply. Users could use front
panel or communication interface （TRAN ON AND TRAN OFF） to make it work or not，
Please setting parameters before transition operation. Include Transition setting value,
Constant pulse width setting and Transition Pulse width setting and Transition testing
mode. The mix pulse width is 500uS.The Max pulse width is 6S. Transition Operation
only could work in CC and CV mode.
Users can choose one of the three operation modes: Continuous, Pulse and Toggling
mode.
Transition Parameter Setting
Users could press
Shift
+
S-Tran
ENTER
ENTER
ENTER
ENTER
ENTER

Continuous Transient Operation

In this mode, electronic load will generates a repetitive pulse stream that
toggles between two load levels. ; Load could switch the state between two
setting value (value A and value B).
In this following example, assume that the CC mode is active; the applicable transient
operation parameters have been set as follows.
S-Tran
Shift
+
LEVEL A = *****
WIDTH A = ******
LEVEL B=*****
WIDTH B= *****
CONTINUOUS
PULSE
TOGGLED
EXIT
to set the transition parameter.
Setup value A
Setup time width of value A
Setup value B
Setup time width of value B
Choose one of the three
transition modes
Finish transition setting
