3. Setting / Reading max input voltage （22H/23H）
st
1 byte
nd
2 byte
rd
3 byte
th
4 byte
th
5 byte
th
6 byte
th
7 byte
th th
From 8 to 25 byte
th
26 byte
NOTE
Represent a voltage upper limit value by 4 bytes of Hex. Lower bytes are in the front
location, higher bytes are in the later location. 1 represent 1mV.For Example : The
voltage upper limit is 16.000V，the hex code is 0X00003EB0，then the 4th byte is
0XB0，5th byte is 0X3E，6th byte is 0X00，7TH byte is 0X00。
4. Setting / Reading the max input current .
（24H/25H）
st
1 byte
nd
2 byte
rd
3 byte
th
4 byte
th
5 byte
th
6 byte
th
7 byte
th th
From 8 to 25 byte
th
26 bye
Start bit ( AAH )
Address (0—0XFE)
Command（22H/23H）
The Lowest byte of max voltage value
The lower byte of max voltage value.
The higher byte of max voltage value.
The highest byte of max voltage value.
System reserve.
Sum code.
Start bit ( AAH )
Address(0—0XFE)
Command（24H/25H）
The Lowest byte of max current value
The Lowest byte of max current value
The higher byte of max current value
The highest byte of max current value
System reserve
Sum code
