ITech IT8511A Manual page 51

NOTE
Represent an current value by 4 bytes of Hex .Lower bytes are in the front location,
higher bytes are in the later location.1 represent 0.1mA,If setting upper limit is
3.0000A，the hex code is 0X00007530，then the 4th byte is 0X30，5th is 0X75，6th
is 0X00，7th is 0X00。
5. Setting / Reading max input power（26H/27H）
st
1 byte
nd
2 byte
rd
3 byte
th
4 byte
th
5 byte
th
6 byte
th
7 byte
th th
From 8 to 25 byte
th
26 byte
NOTE
Represent power value by 4 bytes of Hex. Lower bytes are in the
Front location, higher bytes are in the later location. 1 represents 1mW. If setting
upper value is 200.000W，the hex code is 0X00030d40，then the 4th byte is
0X40，5th is 0X0d，6th is 0X03，7th is 0X00。
6. Selecting / Reading CC/CV/CW/CR operation
mode of Electronic load.（28H/29H）
st
1 byte Start bit ( AAH )
nd
2 byte Address (0—0XFE)
rd
3 byte Command（28H/29H）
th
Mode（0 is CC mode, 1 is CV mode , 2 is CW mode , 3 is CR mode ）
4 byte
th
From 5 System reserve
th
To 25 byte
th
26 byte Sum code
Start bit ( AAH )
Address (0—0XFE)
Command（26H/27H）
The lowest byte of max power value.
The lower byte of max power value
The higher byte of max power value.
The highest byte of max power value.
System reserve
Sum code
