ITech IT8511A Manual page 56

14. Setting /Reading CR mode transient
resistance and timer parameter（38H/39H）
st
1 byte
nd
2 byte
rd
3 byte
th th
From 4 byte to 7
byte
th th
From 8 byte to 9
byte.
th
From 10 byte to
th
13 byte
th
From 14 byte to
th
15 byte
th
16 byte
th th
17 byte to 25
byte
th
26 byte
15．Selecting /Reading the list operation mode
(CC/CV/CW/CR)（3AH/3BH）
st
1 byte
nd
2 byte
rd
3 byte
th
4 byte
th
From 5 to 25 byte
th
26 byte
Start bit ( AAH )
Address (0—0XFE)
Command（38H/39H）
Setting value of resistance A (Lower bytes are in the front location,
higher bytes are in the later location)
Time value of timer A (Lower bytes are in the front location, higher
bytes are in the later location)
(1 represent 0.1mS)
Setting value of resistance B (Lower bytes are in the front location,
higher bytes are in the later location)
Time value of timer B (Lower bytes are in the front location, higher
bytes are in the later location)
(1 represent 0.1mS)
Transition operation mode (0 is CONTINUES,1 is PULSE,2 is
TOGGLED)
System reserve
Sum code
Start bit ( AAH )
Address (0—0XFE)
Command（3AH/3BH）
LIST operation mode（0is CC mode，1 is CV mode ,2 is CW mode,3
is CR mode）
System reserve
Sum code
56
