EAS30017

CHASSIS TIGHTENING TORQUES

Item
Upper handlebar holder bolt
Front brake caliper bolt
Brake caliper bleed screw
Front wheel axle nut
Rear brake caliper bolt
Rear wheel axle nut
Upper bracket pinch bolt
Lower bracket pinch bolt
Steering stem nut
Lower ring nut
TIP
1. Tighten the lower ring nut 48 N·m (4.8 kgf·m, 35 lb·ft) with a torque wrench and the steering nut
wrench, and then loosen the nut completely.
2. Tighten the lower ring nut 14 N·m (1.4 kgf·m, 10 lb·ft) with a torque wrench and the steering nut
wrench.
Thread
Q'ty
size
M8 4
M10 2
M7 2
M14 1
M10 2
M16 1 125 N·m (12.5 kgf·m, 92 lb·ft)
M8 2
M10 2
M22 1
M22 1
2-12
TIGHTENING TORQUES
Tightening torque
21 N·m (2.1 kgf·m, 15 lb·ft)
35 N·m (3.5 kgf·m, 26 lb·ft)
6 N·m (0.6 kgf·m, 4.4 lb·ft)
52 N·m (5.2 kgf·m, 38 lb·ft)
35 N·m (3.5 kgf·m, 26 lb·ft)
23 N·m (2.3 kgf·m, 17 lb·ft)
30 N·m (3.0 kgf·m, 22 lb·ft)
91 N·m (9.1 kgf·m, 67 lb·ft)
See TIP.
Remarks
LS
LS
