9.3. Measuring Data
Measuring Data
Principle of Measurement
As per standard (varies by model)
Status indication
Limits indication
Probe type
Measuring range
Measuring interval
Units
Display resolution
Measurement uncertainty*
(based on factory standards)
Minimum measuring area
Minimum curvature radius, convex
(accuracy tested up to 250 μm)
Minimum thickness of the base material
(accuracy tested up to 250 μm)
* Accuracy may deviate outside a range of -5 °C to 65 °C, but not more than the factor 2 of the
measurement uncertainty
44
Fe
Magnetic field principal,
Magnetic field change,
Hall effect
DIN EN ISO 2808,
DIN EN ISO 2178
DIN 50981, DIN 50984, BS 5411 (3 & 11), BS 3900-C5,
ASTM B 499, ASTM D 1400, ASTM D 1186, ASTM D 7091
By RGB-LED at the probe
By RGB-LED at the probe
See probe data sheet
Varies by probe type
≥ 100 measurements / min
μm / mil
0,01 μm
± (1 μm + 2 %) to 2 mm
± 3 % from 2 mm
14,5 mm ø
4 mm with 2-point-adjust-
ment (zero and 250 μm)
on original substrate
6 mm with zero adjustment
on original substrate
25 μm with 2-point-adjust-
ment (zero and 250 μm)
on original substrate
100 μm with zero adjustment
on original substrate
NFe
Magnetic field principal,
Eddy current
DIN EN ISO 2808,
DIN EN ISO 2360
± (2 μm + 2 %) to 2 mm
± 3 % from 2 mm
14,5 mm ø
30 mm with 2-point-adjustment
(zero and 250 μm) on original
substrate
50 mm with zero adjustment on
original substrate
20 μm with 2-point-adjustment
(zero and 250 μm)
on original substrate
50 μm with zero adjustment on
original substrate
