Automation Dr. Nix QNix 9500 Operation Manual page 23

Section
Measurement
range
μm / mil
294.3
291.0
316. 1
Analysis area
Probe status
Assignment
Menu key
Assignment
Q
Q button
Symbols Description
n: Number of spots used in the enabled area
Number of measurements used for averaging, if over 5 values the
display will show a number. filled boxes correspond to the number
of measurements recorded
Unit for the coating thickness
Current measurement (within the limits)
Not all measurements for averaging have been recorded
Measurement outside the limits
n-1
Last and next to last measurement
n-2
NFe / Fe Substrate setting of the current measurement
Note: The analysis area is split into three areas: Graphics, statistics
and conformance. This describes the area statistics value. For
more information, please see chapter „Analysing Measurements".
x –
Average
x-max Highest measurement
x-min Lowest measurement
σ
Standard deviation
Probe connected
Switch to menu (On/Off button)
Switch directly to measurement
›
Manually advance area (with Q button assigned accordingly;
QNix® 9500P and QNix® 9500P+ only)
›
All areas disabled
Start adjustment (with Q button assigned accordingly)
In menu: one level up
When selecting a limit set: Open settings
23
