4.5. Measure and Save
Notice

Check device

Check the device with the zero plates before every job and calibrate if necessary.
Zero with the uncoated original substrate for optimal measurements.
• Select job (QNix® 9500P+ only)
• Enable start area (QNix® 9500P and QNix® 9500P+); typically area 0001
NOTICE Measurements are always saved to the enabled area.
• If necessary, calibrate or select a saved adjustment
• Apply the probe and take a measurement
NOTICE If measurements are already stored under the job / area, a warning will appear.
Overwrite the measurements or select a different job.
• Analyse the data on the PC in QN9.
4.6. Analysing Measurements
You can already navigate through measurements whilst the test is running to analyse these and if
necessary erase individual values, or erase the measurements in an area or an entire series of measure-
ments. If limits are set, an icon indicating if the measurements are within / above the limits will appear in
the status bar and the measurement area::
Erase individual measurement
• Use the
• Use the
• Use the Q button (paper bin) to erase the measurement
Erase all measurements in an area (QNix® 9500P and Qnix® 9500P+)
• Open the „Jobs" menu. The current job is highlighted.
Press OK to confirm: The current job will open with the current area selected..
•
• Select the desired area and press OK to confirm.
26
and buttons to set the focus frame to the measurement area
and buttons to select the measurement
