4.3.1. Focus Frame
You can already navigate through measurements whilst the test is running to analyse these or erase
individual values. To do so, open the focus frame with the
area.
Use the
and
buttons to navigate between „Job/Area", „Measurement area" and „Analysis area".
The focus frame will highlight the selected area..
Navigation job/area bar
Navigating the measurement area
Navigating the analysis area
Notice
View limits
This display varies based on the selected limit sets. The example shows a view with „simple limits"
and averaging selected.
Default
Navigate left
Navigate right
24
Use
With the measurement area selected, use the
to browse recorded measurements and if necessary press the
Q button (paper bin) to erase these.
Use the
types of statistics.
Overview of minimum / maximum measurement, average and standard deviation
Shows the measurements in a bar diagram; displays the selected limits,
minimum / maximum measurement and current measurement
Number of spots saved in the area; limit condition met or exceeded
and
buttons and navigate to the desired
and
buttons to swap the active area.
and
buttons in the analysis area to view three
and
buttons
