„Select „Erase measurements" and press OK to confirm. A confirmation message will appear..
•
•
Use the
NOTICE! A confirmation will not appear, the measurements in the selected area have been
erased
•
If necessary, enable the selected area and repeat the measurement.
4.7. Editing Areas ( QNix® 9500P and QNix® 9500P+)
4.7.1. Configuring Areas
With models QNix® 9500P and QNix® 9500P+ you can configure several areas for one job (see chart in
previous chapter). You can assign a different limit set for each area..
•
Select the „Jobs" menu.
Select job and press OK to confirm. The existing areas will be displayed.
•
•
Select „New area" and press OK to confirm. The new area has been added.
The limits for the enabled area will be applied.
To configure a different limit set for the new area:
Select „Enable area" and press OK to confirm. This will enable the area.
•
•
Use the navigation buttons
•
Select the limits set and if necessary adjust (also see chapter „Configure Limits).
•
Return to the „Jobs" menu.
4.7.2. Add area during measurement
There are two options for adding an area during a measurement:
•
Via autorange
•
With the Q button
and
buttons to confirm
and
and press OK to confirm.
or cancel
to got to the „Limits" menu.
27
