Module programming

Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.
(For skip transponder programming or security-only programming, see following pages.)
IMPORTANT!
1
The vehicle battery must be in good condition and fully charged for successful
programming. A battery charger may be connected during programming if necessary.
Ensure vehicle is in a safe location, and cannot move forward during programming.
2
For vehicles equipped with a manual transmission, make sure the gearshift is in the
neutral position.
Connect the 12-pin main power harness to the module.
DS3+: Wait until the LED turns on solid red then proceed to the next step.
3
DS4+: The LED turns ON solid blue for 1 second to confirm Bluetooth communication.
Wait until the LED turns ON solid red, then proceed to the next step.
4
Connect the remaining harnesses to the module.
Press twice (2) on the Push-to-Start (PTS) button to turn the ignition ON. The LED flashes
orange quickly for approximately 5 seconds, then flashes green (may flash green for
30-60 seconds).
5
Note: If the LED flashes red 3 or 4 times after the initial 30-60 seconds, wait an extra
30 seconds.
If the LED starts flashing orange slowly, Key2GO programming will be required for
your vehicle.
Press the PTS button once (1) more to turn ignition OFF, remove the module from the
vehicle, and reconnect it to your computer. The web site will automatically recognize
6
that you are moving onto the second phase of the programming sequence. Proceed to
step 6.
If however, the LED turns ON solid green for 3 seconds, then shuts OFF, press the PTS
button once (1) more to turn the ignition OFF. The programming sequence was
successfully completed.
7
Click on Submit Key2GO Request.
Once the configuration is completed, reconnect the module.
The LED turns ON solid green for 3 seconds, then shuts OFF.
8
If however, the LED returns to flashing orange slowly, perform a soft reset on the
module. When the LED turns solid red, start the vehicle. The LED will turn ON solid
green for 3 seconds then shuts off.
9
Pair remotes (if applicable).
