Module programming

Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.
Connect the 10-pin, 12-pin and 14-pin harnesses to DB3, then wait until the LED turns ON
1
solid red.
2
Press on the Unlock button on the OEM remote.
3
Make sure the key is inside the vehicle.
Important! Do NOT depress the brake pedal.
4
Press the Push-to-Start (PTS) button once to turn the ignition ON. The LED flashes green.
The LED turns ON solid green for 3 seconds, then turns OFF. Press the PTS button once more
5
to turn the ignition OFF.
You have successfully completed the module programming sequence.
12
403.VW09 2.00 2014 Volkswagen Jetta GLI (Smart Key)
