Wiring Diagram Without Vehicle Takeover - Directed DIRECTECHS DS3+ Installation Manual

Wiring diagram without Vehicle Takeover
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
If the OEM Remote Keyless Entry does
NOT operate when a vehicle is remote
started, disconnect Accessory 2.
(+) Accessory 2: Pin 15
(-) PTS: Pin 11
(+) Ignition: Pin 17
(+) 12V: Pin 18
17 16 15
11
18 14 13 12 10 9
32
36 35 34 33 31 30 29 28
(+) Accessory 1: Pin 16 (+) Starter: Pin 32
Ignition Interrupt:
Pin 34
Cut
16 933.HONDA9 2.03.195.3 2018 Acura ILX (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
2
2
8 7 6 5 4 3 2 1
27 26 25 24 23 22 21 20 19
Keyless Access
Refer to the
Control Unit
Optional starter
(gray connector)
disable connection
section for relay and
connection details.
Headlight Switch
(blue or white connector)
Siren
6 5 4 3 2 1
12 11 10 9 7
8
(-) Parking Lights:
pin 8 OR pin 11
Keyless Acces Control Unit
1
(Refer to the Vehicle connections
section for the location of this unit.)
Keyless Access Control Unit
(gray connector)
B-CAN
1
High:
Pin 1
10 9 8 7 6 5 4 3 2 1
20 19 18 17 16 15 14 13 12 11
B-CAN
Low:
Immo. Data:
F-CAN F-CAN
Pin 11
Pin 5
High: Low:
Pin 2 Pin 12
Hood Pin
Ignition Interrupt (vehicle side): Blue/White: 1
HS CAN Low 2: Tan: 1
HS CAN High 2: Tan/Black: 2
A
this installation.
HS CAN Low 1: Orange/Brown: 3
HS CAN High 1: Orange/Green: 4
Immobilizer Data: Yellow/Black: 8
(-) Push-to-Start Output: Lt. Green/Black: 1
(-) GWA Output: Red/White: 4
(+) Accessory 2 Output: White: 7
(+) Starter Output: Violet/Black: 8
(-) Parking Lights Output: Lt. Blue/Black: 10
(+) Siren Output: Brown/Red: 11
(-) Hood Input: Gray: 21
Ignition Interrupt (connector side): Blue: 3
(+) Accessory 1 Output: White: 5 & 11
(+) 12V Input : Red: 6 & 12
(+) 12V Input: Lt. Green/Red: 7
(+) Ignition Output: Lt. Green: 8
(-) Ground: Black: 10
).
module can also be used for
IMPORTANT:
Position the
fuses correctly!
Slide to open
Legend:
Mandatory Connections
Security Only
Remote Start Only
Remote Start + Security
