Vehicle connections

The connection information listed below is specific to the 2018 Acura ILX (Smart Key). Refer to "Pre-installation and application warnings" for a list of important notes.
Data harness, 8-pin white connector (H1)
Module
Conn./Pin Color Description
H1/1 Tan (Data) HS CAN Low 2
H1/2 Tan/Black (Data) HS CAN High 2
H1/3 Orange/Brown (Data) HS CAN Low 1
H1/4 Orange/Green (Data) HS CAN High 1
H1/5 Lt. Green No Connection
H1/6 Violet/Brown (-) Takeover 2 Output - Required for
installations with vehicle takeover ONLY.
H1/7 Orange/Black No Connection
H1/8 Yellow/Black (Data) Immo. Data
Analog input/output harness, 22-pin white connector (H2)
Module
Conn./Pin Color Description
H2/1 Lt. Green/Black (-) PTS Output [6]
H2/2 Blue/White (-) Clutch Activation Output
H2/3 Dk. Green/Black (-) Lock Output
H2/4 Red/White (-) Ground When Armed (GWA) Output [4]
H2/5 Brown/Black (-) Horn Output
H2/6 Brown/White (-) AUX 1 Output
18 933.HONDA9 2.03.195.3 2018 Acura ILX (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Connects To
Wire Location
Keyless Access Control Unit right of steering column, gray 20
pin plug, pin 11
Keyless Access Control Unit right of steering column, gray 20
pin plug, pin 1
Keyless Access Control Unit right of steering column, gray 20
pin plug, pin 12
Keyless Access Control Unit right of steering column, gray 20
pin plug, pin 2
No Connection
Must use (2) 8616 mini relays.
Must use (2) 1N4002 diode or larger.
5A fuse to 12V.
Keyless Access Control Unit right of steering column, gray 36
pin plug, pin 30
No Connection
Keyless Access Control Unit right of steering column, gray 20
pin plug, pin 5
Connects To
Wire Location
Keyless Access Control Unit right of steering column, gray 36
pin plug, pin 11
No Connection
No Connection
Starter:
Keyless Access Control Unit right of steering column, gray 36
pin plug, pin 32
Ignition:
Keyless Access Control Unit right of steering column, gray 36
pin plug, pin 17
Must use a relay.
Must use a 1N4002 diode or larger.
Horn Switch-Clock Spring or Dash Fuse Box, white 38 pin plug
(C), pin 35
No Connection
(+/-) Wire Color Connection
Data Blue (B-CAN) Mandatory
Data Pink (B-CAN) Mandatory
Data Red (F-CAN) Mandatory
Data White (F-CAN) Mandatory
Cut Red Remote Start
Only
Data Gray Remote Start
Only
(+/-) Wire Color Connection
- Green Remote Start
Only
+ Yellow Security Only
+ White
- Orange to Pink Optional
