Module programming

Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.
For Convenience-Only programming, see next section.
1
Ensure vehicle is in a safe location and cannot move forward during programming.
The harnesses must be connected in this exact order:
Connect the 14-pin.
1.
2
2. Connect the 12-pin.
3. Connect the 10-pin.
When the LED turns on solid red, proceed with the next step.
Press the brake pedal then press the Push-to-Start (PTS) button once (1) to start the vehicle.
3
The LED flashes green then orange slowly.
4
Press the PTS button once (1) more to turn the ignition OFF.
Remove the module from the vehicle and reconnect it to your computer. The website
1.
will automatically recognize that you are moving onto the second phase of the
5
programming sequence.
Click Submit Key2GO Request.
2.
When the configuration is completed, reconnect the module.
6
The LED will turn ON solid green for 3 seconds, then turn OFF.
You have successfully completed the module programming sequence.
9
403.TL17 1.02 2022 Toyota Corolla Cross (Smart Key)
