Module programming

Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.
Ensure vehicle is in a safe location and cannot move forward during programming. For
1
vehicles equipped with a manual transmission, make sure the gearshift is in the neutral
position.
The harnesses must be connected in this exact order:
1. Connect the 14-pin.
2. Connect the 12-pin.
2
3. Connect the 10-pin.
4. Connect the 4-pin D2D cable (if being used).
When the LED turns ON solid red, proceed with the next step.
Turn the key to ignition position.
3
The LED will start to flash green and orange.
Press Unlock on the factory key fob (if not available, press the programming button 5 times).
4
The LED turns ON solid orange for 3 seconds then shuts off.
5
Turn vehicle ignition OFF.
You have successfully completed the module programming sequence.
11
403.GM7 4.11 2005 Pontiac G6
