Directed DIRECTECHS DS3+ Installation Manual page 20

Module
Conn./Pin Color Description
H3/4 White/Brown Relay N.C. (+) Accessory Interrupt 1 (connector
side)
H3/5 White Relay COM (+) Accessory Output
H3/6 Red (+) 12 Volt Input
H3/7 Lt. Green/Red Relay N.O. (+) 12 Volt Input
H3/8 Lt. Green Relay COM (+) Ignition Output/Interrupt
(vehicle side)
H3/9 Lt. Green/White Relay N.C. Ignition Interrupt (conn. side)
H3/10 Black (-) Ground
H3/11 White Relay COM (+) Accessory Output
H3/12 Red (+) 12 Volt Input
Relay harness, 10-pin white connector (H4)
Module
Conn./Pin Color Description
H4/1 N/A No Connection
H4/2 Red/Black (+) 12 Volt Input
H4/3 Pink/Black Flex Relay (pin 87a)
H4/4 Pink/White (+) Flex Relay Output
H4/5 Red (+) 12 Volt Input
H4/6 Green Starter Input (conn. side)
H4/7 Violet (+) Starter Output (vehicle side)
H4/8 Orange (+) Accessory Output
H4/9 Red/White (+) 12 Volt Input
H4/10 Pink (+) Ignition Input/Output
RF Port harness, 2-pin white connector (H5)
Module
Conn./Pin
H5/1
H5/2
20 933.HONDA9 2.03.195.3 2018 Acura ILX (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Connects To
Wire Location
No Connection
Keyless Access Control Unit right of steering column, gray 36
pin plug, pin 16
Keyless Access Control Unit right of steering column, gray 36
pin plug, pin 18
Keyless Access Control Unit right of steering column, gray 36
pin plug, pin 18
Keyless Access Control Unit right of steering column, gray 36
pin plug, pin 17
Keyless Access Control Unit right of steering column, gray 36
pin plug, pin 17
Required for installations with vehicle takeover ONLY.
Keyless Access Control Unit right of steering column, gray 36
pin plug, pin 16
Keyless Access Control Unit right of steering column, gray 36
pin plug, pin 18
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
Color
N/A
N/A
(+/-) Wire Color
+ Gray
+ Green (10A)
+ Green (10A)
+ White
+ White
(chassis ground)
+ Gray
+ Green (10A)
(+/-) Wire Color
Description
RF Loop
RF Loop
Connection
Remote Start
Only
Mandatory
Remote Start
Only
Mandatory
Remote Start
Only
Mandatory
Remote Start
Only
Mandatory
Connection
