Vehicle Takeover Additional Connections - Directed DIRECTECHS DS3+ Installation Manual

Vehicle takeover additional connections

Hardwire installations - required for takeover. For T-Harness installations, DO NOT make connections on this diagram, they have relays built-in.
•
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
•Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
(+) 12V: Pin 18
Cut
8616 wire and color reference
Orange
Brown
Yellow
Black
14 933.HONDA9 2.03.195.3 2018 Acura ILX (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Keyless Access Control Unit
(gray connector)
18 17 16 15 14 13 12 11 10 9 8 7 6 5 4
36 35 34 33 32 31 30 29 28 27 26 25 24 23 22
(+) Ignition (+) Ignition Interrupt 4:
Interrupt 1: pin 30
pin 34
8616 8616
Mini Mini
Cut
Relay Relay
87 87a 87 87a
85 86 85 86
30 30
1A Diode (1N4002+) 1A Diode (1N4002+)
8616
Mini
Relay
87 87a
Red
85 86
30
Keyless Acces Control Unit
2
(Refer to the Vehicle connections
section for the location of this unit.)
2
3 2 1
21 20 19
5A Fuse
A
this installation.
(-) Takeover 2 Output: Violet/Brown: 6
(-) Takeover 1 Output: Dk. Blue/Black: 9
(+) 12V Input : Red: 6 & 12
(-) Ground: Black: 10
).
).
module can also be used for
IMPORTANT:
Position the
fuses correctly!
Slide to open
Legend:
Mandatory Connections
Security Only
Remote Start Only
Remote Start + Security
