Wiring diagram with Vehicle Takeover
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
(+) Ignition: Pin 17
Keyless Access Control Unit
(gray connector)
Cut
18 17 16 15 14 13 12 9
11 10
(+) 12V:
36 35 34 33 32 31 30 29 28
Pin 18
(+) Accessory:
(-) PTS: Pin 11
Pin 16
(+) Starter:
Green or Lt.Blue,
pin 32
Headlight Switch
(blue or white connector)
6 5 4 3
12 11 10 9
13 933.HONDA9 2.03.195.3 2018 Acura ILX (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
2
2
8 7 6 5 4 3 2 1
27 26 25 24 23 22 21 20 19
Refer to the
Optional starter
disable connection
Refer to the next page for the
section for relay
and connection mandatory relay connections
details. for Vehicle takeover.
Siren
2 1
7
8
Ignition Interrupt 5: Pin 12
(-) Parking Lights:
pin 8 OR pin 11
Cut
12
Steering Lock Module
(gray connector under steering column)
Keyless Acces Control Unit
1
(Refer to the Vehicle connections
section for the location of this unit.)
Keyless Access Control Unit
(gray connector)
B-CAN
1
High:
Pin 1
10 9 8 7 6 5 4 3 2 1
20 19 18 17 16 15 14 13 12 11
B-CAN
Low:
Immo. Data:
F-CAN F-CAN
Pin 11
Pin 5
High: Low:
Pin 2 Pin 12
(-) Push-to-Start Output: Lt. Green/Black: 1
(+) Takeover Ignition Output (conn. side): White: 7
(-) Parking Lights Output: Lt. Blue/Black: 10
Hood Pin
Ignition Interrupt (vehicle side): Blue/White: 1
Ignition Interrupt (connector side): Blue: 3
(+) Ignition Output/Interrupt (vehicle side): Lt. Green: 8
(+) Ignition Interrupt (connector side): Lt. Green/White: 9
HS CAN Low 2: Tan: 1
HS CAN High 2: Tan/Black: 2
HS CAN Low 1: Orange/Brown: 3
A
HS CAN High 1: Orange/Green: 4
this installation.
Takeover 2 Output: Violet/Brown: 6
Immobilizer Data: Yellow/Black: 8
(-) GWA Output: Red/White: 4
(+) Starter Output: Violet/Black: 8
(-) Takeover 1 Output: Dk. Blue/Black: 9
(+) Siren Output: Brown/Red: 11
(-) Hood Input: Gray: 21
(+) Accessory Output: White: 5 & 11
(+) 12V Input : Red: 6 & 12
(+) 12V Input: Lt. Green/Red: 7
(-) Ground: Black: 10
).
module can also be used for
IMPORTANT:
Position the
fuses correctly!
Slide to open
Legend:
Mandatory Connections
Security Only
Remote Start Only
Remote Start + Security
