14. OPTIONS
Specification
Specification
Print Method
Resolution
Number of Column
Character set
Character Per Inch
Interface
Data biffer
Print speed
Power
Power consumption
Dimensions(mm)
Weight
Design, Specifications are subject to change without notice. Ask factory for technical
specifications before purchase and/or use. Whenever a doubt arises form this products,
please inform us immediately for technical cosultation without fail.
CLOVER A1c Self • 46 •
SRP-III
Horizontal Direct Thermal
8dots/mm(384dots)
42 columnas ( 9x17)
32 columnas ( 12x4)
95 Alphanumeric, UPCA, UPCE, JAN8(EAN),
CODE39, CODE93, COLE128, ITF, CODABAR
16CPI
RS-232C/Parallel
4Kbytes or 45bytes
35mm/sec (Max.)
9V DC ± 10%
Approx 2.0A(mean)
136(M) x 202(L) x 89(H)
500 g
14. OPTIONS
14.3 Scanner
CLOVER A1c™ Self accepts data input from the following barcode symbologies
Code 93 standard includes check digit
Code 39 with optional check digit required
Code 128 standard includes check digit
CodaBar without check digit
The analyzer is pre-set to use the barcoding system appropriately during the
set-up process. Please refer to page 14.
The barcode scanner can be used to scan the patients ID.
All the patients' information is stored in the analyzer for future reference. Connect
the barcode scanner to the analyzer.
USB Barcode
On/Off 9V
When performing your test with the barcode system
STEP 1. Open the cover of CLOVER A1c™ Self
analyzer
STEP 2. Insert the cartridge when the 'Cartridge
insert' icon is displayed.
STEP 3. The LCD display will prompt you to 'scan
carcode'.
CLOVER A1c Self • 47 •
Printer
