Infopia CLOVER A1c Self Instructions For Use Manual

Test analyzer
Hide thumbs
Table of Contents

Advertisement

Quick Links

infopia Co., Ltd.
891, Hogye-Dong, Dongan-Gu,
Anyang, Kyunggi, 431-080, Korea
www.infopia21.com
Obelis S.A.
Bd. General Wahis 53
1030 Brussels, Belgium
Tel : +(32) 2.732.59.54
Fax : +(32) 2.732.60.03
E-Mail : mail@obelis.net
IMH12-008
Rev.2011-12-01
Diabetes Management Technology
INSTRUCTION FOR USE
For measuring Hemoglobin A1c
For measuring Hemoglobin A1c
For measuring Hemoglobin A1c
INFH01AS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CLOVER A1c Self and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Infopia CLOVER A1c Self

Summary of Contents for Infopia CLOVER A1c Self

  • Page 1 Diabetes Management Technology INSTRUCTION FOR USE infopia Co., Ltd. 891, Hogye-Dong, Dongan-Gu, Anyang, Kyunggi, 431-080, Korea www.infopia21.com Obelis S.A. Bd. General Wahis 53 1030 Brussels, Belgium Tel : +(32) 2.732.59.54 Fax : +(32) 2.732.60.03 E-Mail : mail@obelis.net INFH01AS For measuring Hemoglobin A1c...

  • Page 2: Table Of Contents

    10. SETTING THE ANALYZER 11. TESTING HbA1c 12. REVIEWING RESULTS 13. CHECKING THE SYSTEM 14. OPTION 15. PRODUCT LIST 16. TROUBLESHOOTING 17. SPECIFICATION 18. MAINTENANCE 19. SAFETY 20. DISPOSAL 21. PRECAUTION 22. SYMBOL & DESCRIPTION CLOVER A1c Self • 3 •...

  • Page 3: Intended Use

    1. INTENDED USE 3. PRINCIPLES OF OPERATION The CLOVER A1c Self analyzer is an IVD(In Vitro Diagnostic Device) device for The CLOVER A1c™ Self system is a fully automated boronate affinity assay for the measuringHemoglobin A1c by the well established method of boronate affinity. It is able determination of the percentage of Hemoglobin A1c (HbA1c %) in whole blood(capillary to analyze bothcapillary whole blood and venous blood.

  • Page 4: Storage Instructions

    Solution Cartridge Mixing 5times Code Area For use with CLOVER A1c Self Test Cartridge only For measuring hemoglobin A1c For Self-testing use 5. Storage Instructions The CLOVER A1c™Self analyzer must be stored at 10°C~35°C. Test Cartridges must Sample Collecting Area be stored at 2°C~32°C(36°F-90°F) and 10%~90% R.H( Relative Humidity)

  • Page 5: List Of Icons

    Memory in memory. capillary tip area. Insert reagent pack with blood sample Insert Reagent Set up Select this icon to set up the analyzer. into the analyzer. Pack CLOVER A1c Self • 8 • CLOVER A1c Self • 9 •...

  • Page 6: Installation

    Connect the System Power 1. Ensure that the system power button is in the off position. 2.Connect the power code of the system to appropiately grounded AC electrical outlet. CLOVER A1c Self • 10 • CLOVER A1c Self • 11 •...

  • Page 7: Setting The Analyzer

    Select the time format by pressing the DATE yy/mm/dd 08 / 03 / 30 buttons, then press 12h for standard time / 24h for military time TIME AM 08 : 00 CLOVER A1c Self • 12 • CLOVER A1c Self • 13 •...
  • Page 8 Select whether or not to use the barcode system by pressing , then press Set up the contrast desired, by pressing the then press LCD Contrast Barcode Use Not Use CLOVER A1c Self • 14 • CLOVER A1c Self • 15 •...

  • Page 9: Testing Hba1C

    Code Area of the front side, nor the bead window at the back side. Any dirt or contamination of both areas, may cause erroneous test values. Code Area IMPORTANT : Do not move the analyzer during the ‘Warming up’. Bead Window CLOVER A1c Self • 16 • CLOVER A1c Self • 17 •...
  • Page 10 08/03/30 AM10:02 08/03/30 AM10:02 HbA1c Glucose HbA1c Glucose IMPORTANT : After the capillary tip is filled with sample, analysis must begin within 5 minutes. CLOVER A1c Self • 18 • CLOVER A1c Self • 19 •...
  • Page 11 ▪ Follow all hygiene and safety regulations in force locally. [ adequate ] [ inadequate ] IMPORTANT : Once the reagent pack is filled with the blood sample, analysis must begin immediately. CLOVER A1c Self • 20 • CLOVER A1c Self • 21 •...
  • Page 12 Do not vibrate or move the analyzer during the test. CAUTION : Do not give strong impact to cartridge. Dispose all waste in accordance with applicable national and /or local regulations. CLOVER A1c Self • 22 • CLOVER A1c™ Self • 23 •...
  • Page 13 Hemoglobin concentrations are outside of the acceptable range. CAUTION : Discard cartridge in proper container, according to your standard laboratory procedures. CLOVER A1c Self • 25 • CLOVER A1c Self • 24 •...

  • Page 14: Reviewing Results

    STEP 2. No.46 Press either the button to select between 'HbA1c' and 'Glucose', mmol/mol then press 08/11/08 PM12:03 Memory Memory HbA1c HbA1c / Glucose No.45 mmol/mol 22356789012341 08/10/08 PM12:35 CLOVER A1c Self • 27 • CLOVER A1c Self • 26 •...

  • Page 15: Checking The System

    Daily check cartridge The CLOVER A1c™ Self Check Cartridge checks that the optical and operating systems of the Analyzer are working correctly. For checking CLOVER A1c Self Analyzer only. For self-testing use. IMPORTANT : Please read through and familiarize yourself with the contents of theCLOVER A1c™Self Analyzer Operation Manual before...
  • Page 16 NOTE : If an errer message is displayed, repeat the test. If is still displays Er 2 message ‘Do Not use the analyzer’. NOTE : To leave the Daily check cartridge mode, press for 3 seconds. Please contact your local representative for customer support. CLOVER A1c Self • 31 • CLOVER A1c Self • 30 •...
  • Page 17 - If Monthly Check Cartridge be reused, analyzer show up ‘Do not reuse!’. - The Monthly check cartridge can be purchased from local distributors. NOTE : To leave the Monthly check cartridge mode, press for 3 seconds. CLOVER A1c Self • 32 • CLOVER A1c Self • 33 •...
  • Page 18 NOTE : If an error message is displayed, repeat the check again. If it still displays error message ‘Do Not use the analyzer’. Please contact your local representative for customer support. CLOVER A1c Self • 34 • CLOVER A1c Self • 35 •...
  • Page 19 2) Insert the cartridge when the ‘Cartridge insert’ icon displayed. [ adequate ] [ inadequate ] IMPORTANT : Once the reagent pack is filled with the control solution, analysis must begin immediately. CLOVER A1c Self • 36 • CLOVER A1c Self • 37 •...
  • Page 20 - Please contact your local representative for customer support. 6) The HbA1c% is displayed after 5 minutes. NOTE : The test result should be within the range speccified on the manual of the respective control solution. CLOVER A1c Self • 38 • CLOVER A1c Self • 39 •...
  • Page 21 STEP 2. Connect the blood glucose Module to the port located in the front side of STEP 5. Check the applying sample blood icon on the CLOVER A1c™ Self the Analyzer. anlayzerLCD. CLOVER A1c Self • 40 • CLOVER A1c Self • 41 •...
  • Page 22 STEP 3. Press to select one or the other and or press • Current : Only that result will print. • ALL : Every result in memory will print. CLOVER A1c Self • 42 • CLOVER A1c Self • 43 •...
  • Page 23 Paper Roll - Don’t touch the print head. It can be very hot after printing continuously for a long time. - Make sure that the paper direction is correct. CLOVER A1c Self • 44 • CLOVER A1c Self • 45 •...
  • Page 24 Design, Specifications are subject to change without notice. Ask factory for technical specifications before purchase and/or use. Whenever a doubt arises form this products, please inform us immediately for technical cosultation without fail. CLOVER A1c Self • 46 • CLOVER A1c Self • 47 •...
  • Page 25 STEP 3. Download the PC application program. STEP 4. Once the program is downloaded, click the ‘Date Transfer’ icon on your PC. The results from the analyzer will be transferred over. CLOVER A1c Self • 48 • CLOVER A1c Self • 49 •...
  • Page 26 1 PC Cable the test cartridge and remove the cartridge. Insert a new test CLOVER A1c™ Self cartridge and perform the test again. 1 Fan fileter AC-CL0-1A2-01 Fan Filter CLOVER A1c Self • 50 • CLOVER A1c Self • 51 •...
  • Page 27 If the problem validate the analyzer and re-test the Er 10 auto-coding label than 4.0% persist, contact your local representa- blood sample. (20mmol/mol) tive. CLOVER A1c Self • 53 • CLOVER A1c Self • 52 •...
  • Page 28 If the problem still persists, does not adaptor or the PC Connection Cable contact your local representative. analyzer itself power on Thermal Printer Barcode Scanner CLOVER A1c Self • 54 • CLOVER A1c Self • 55 •...
  • Page 29 STEP 4. Gently wipe the cartridge compartment. Be careful not to drip any STEP 3. Close the fan filter cover. liquids into the system. NOTE Additional Fan Filter can be purchased from our representatives, nearest in your area. CLOVER A1c Self • 56 • CLOVER A1c Self • 57 •...
  • Page 30 EEE waste going for final disposal. before testing, and visually check if the beads are not coagulated. infopia Co., Ltd. as the manufacturer, has specific instructions for the recovery of the analyzer. Please contact our representatives in your area for the respective instructions before disposing.
  • Page 31 14. Besides, when any kind of errors happen as specified in the manual, refer to the troubleshooting instructions from the Analyzer instruction for use. CLOVER A1c Self • 60 • CLOVER A1c Self • 61 •...
  • Page 32 Waste Electrical and Electronic Equipment Serial number This symbol indicates that the system is type A equipment, which provides a particular degree of protection against electric shock. Manufacturer CLOVER A1c Self • 62 • CLOVER A1c Self • 63 •...
  • Page 33 CLOVER A1c Self • 64 •...
