Board Layout

1. Keyboard controller
2. SMC37C665GT I/O chip
3. PS/2 mouse connector
4. Keyboard connector
5. Power connector
6. Parallel connector
7. COM 1 connector
8. COM 2 connector
9. FDC connector
10. IDE 2 connector
11. IDE 1 connector
12. 72-pin SIMM sockets
13. 82438 ASIC chip
14. Voltage regulator
User's Guide
Features
15. Second-level cache
16. 4-pin fan connector
17. 2-pin fan connector
18. HDD LED connector
19. Multifunction connector
20. ZIF-type CPU socket
21. Battery/RTC
22. 82437 ASIC chip
23. TAG RAM
24. System BIOS
25. 82371 ASIC chip
26. ISA slots
27. PCI slots
1-3
