Features

Expansion Slots

The board expansion slots consist of three PCI slots, three ISA-AT
slots and one PCI-/ISA-shared slot. These expansion slots are the
parallel bars on the system board. There are rows of golden pins
inside each slot that serve as a clutch to secure the contacts of
expansion boards. Chapter 2 tells how to install expansion boards.

DRAM Sockets

The system board has six 72-pin DRAM sockets that expand system
memory to a maximum of 128 MB. These sockets accept single- and
double-density SIMMs. Chapter 2 tells how to install memory
modules and the different memory configurations available.
Two-Channel PCI Mode 4 Enhanced-IDE Controller
The board integrates a two-channel PCI mode 4 enhanced-integrated
drive electronics (E-IDE) controller that improves data transfer rate
and supports bus master IDE. It also has E-IDE interfaces that allow
the system to support four E-IDE devices, including hard disks with
more than 528-MB capacity. This feature offers users increased data
storage capacity.
User's Guide 1-5
