AOpen AX4B Max Easy Installation Manual

CD-IN Connector
JP37/38 CENTER/LFE OUT
Switch
AUX-IN Connector
SPDIF Connector
Onboard AC'97 CODEC
Front Audio Connector
CNR Expansion Slot
32-bit PCI Expansion Slot x6
(AX4B Max: PCI 5&6 Slave
AX4B U2: PCI 5 Slave)
Dr. LED Connector
rd th
3 and 4 USB Connectors
JP35 AGP 1.5V Adjustable
WOL Connector
IrDA Connector
JP30 Die Hard BIOS Select Jumper
Die Hard BIOS (1 default, 1 optional)
IEEE 1394 Connector x2
(AX4B Max only)
nd
2 USB Connector
FAN3 Connector
Front Panel Connector
JP1 Buzzer Jumper
JP14 CMOS Clear Jumper
Chassis Intrusion Connector
FDD Connector
PS/2 Mouse
SPP/EPP/ECP Parallel Port
Connector
PS/2 Keyboard
USB Port
COM 1 Port
Connector
MIDI/Game Port
COM 2 Port
MIC-In
Line-In
Speaker Out
JP28 Keyboard/Mouse Wakeup
Enable/Disable Jumper
Resettable Fuse
FAN2 Connector
4-pin 12V. ATX Power Connector
3300 μ F Low ESR Capacitors
AGP 4x Expansion Slot
(for 1.5V AGP card)
478-pin CPU socket with Voltage and
Frequency Auto-detection supporting
® ®
Intel Pentium 4
®
Intel 845 chipset (Brookdale)
CPU Fan Connector with H/W
Monitoring Function
184-pin DIMM Socket x4 supports
DDR200/266 DDR SDRAM
maximum up to 2 GB
WOM Connector
JP15 & 16 Dr. Voice Language
Select Jumper
JP2 Speaker Jumper
ATX Power Connector
ATA/33/66/100 IDE Connector x2
