AMI BIOS
PCI Secondary IDE INT# Line
This parameter lets you assign an INT for the IDE device connected
to your secondary IDE connector. The settings are INT A, INT B, INT
C, INT D, Absent and Not Used. If you do not have any PCI IDE card
installed in your system and your PCI IDE Card Selection parameter
setting is Absent , this parameter becomes non-configurable.
NCR810 Card Used Slot
This parameter lets you choose where to install the NCR810 SCSI
card. The options are Slot 1, Slot 2, Slot 3 and Slot 4.
PCI Slot 1, 2, 3, and 4
These functions allow you to assign an IRQ for each PCI slot in use.
The selections are IRQs 3, 4, 5, 7. 10, 11, 12, Auto and None.
Selecting enables the BIOS to automatically assign an
Auto
available IRQ for the selected PCI slot. Select if the PCI slot is
None
not in use or to disregard the slot. The default setting is Auto .

IRQ Allocated

IRQ 3, 4, 5, 7, 9, 10, 11, 14, 15 is for...
These lines allow you to assign the available IRQs to either ISA or
PCI/PnP device.
User's Guide 3-21
