HDMI Wireless Extender

sPECIFICAtIOn

Power supply
HDMI
performance
and interface
Wireless
performance
and interference
IR performance
and interface
Protection level Electrostatic protection of
Operating
environment
Body
proprieties
Maintenance: clean only with a dry cloth. Do not use cleaning
solvents or abrasives.
Warranty: no guarantee or liability can be accepted for any changes
and modifications of the product or damage caused due to incorrect
use of this product.
In compliance with EU Directive WEEE this product is marked
with this symbol. It means that used electrical and electronic
products should not be mixed with general household waste.
There is a separate collections system for these products in
compliance with WEEE directive, otherwise contaminative and
hazardous substances can pollute the environment.
With the CE sign, Techly
conformed to the basic European standards and directives.
Voltage/Current
Power consumption
HDMI compliance
HDCP compliance
HDMI resolution
supported
Audio formats supported
Maximum transfer rate
Input and output TMDS
signal
Input and output DDC
signal
Input cable lenght
supported
Output cable lenght
supported
Transmission method
Transmission distance
Latency
IR remote control
the whole machine
Working temperature
Storage temperature
Humidity (no
condensation)
Dimension
Color
Weight
TX: DC5V/1A; RX: DC5V/2A
TX <3W RX <5W
HDMI1.3
HDCP1.2
480i@60Hz, 480p@60Hz,
576i@50Hz, 576p@50Hz,
720p@50/60Hz,
1080i@50/60Hz,
1080p@50/60Hz
L/R stereo audio
10.2 Gbps
0.7~1.5Vp-p (TMDS)
5Vp-p(TTL)
≤5m (AWG26 HDMI 1.3
standard cable)
≤5m (AWG26 HDMI 1.3
standard cable)
5G Wireless transmission
50 meters
≤200 ms
Support IR Pass-back with
20~60KHz frequency
1a Contact discharge level 3
1b Air discharge level 3
Standard IEC61000-4-2
0°C – 40°C
-20°C – 70°C
0 – 90%
TX: 88.90(L) x 38.88 (P)
x 15.17 (A)mm
RX: 131.65(L) x 95 (P)
x 19.90 (A)mm
Black
TX: 30g RX: 220g
ensures that the product is
®
