HDMI EXTENDER OVER
CAT.6/7 CABLE WITH EDID
INTRODUCTION
This HDMI Extender includes a transmitter unit and a receiver unit, allows the HDMI signal to be
transmitted up to 70 meters at 1080p resolution using a Cat6/6A/7 network cable. It adopts a point-
to-point connection configuration, support bi-directional IR pass-back and 3.5 mm stereo audio
output. It is perfect outdoor advertising, monitor system, home entertainment, conference, etc.
FEATURES
1. Zero latency
2. Support up to 1080p@60Hz resolution
3. Supports CAT6/6A/7 network cables, the transmission distance is up to 70 meters
4. Supports bi-directional IR pass-back function (20 ~ 60KHz).
5. Supports 1080p HDR10 YUV4:4:4
6. Supports EDID passthrough
7. Transmitter supports HDMI loop-out
8. Receiver supports 3.5mm stereo audio output
9. Audio formats supported: PCM, LPCM, DTS HD, DTS Audio
10. Automatically adjusts parameters to match different network cables and achieve the best display
performance
11. Lightning Protection, Surge Protection, ESD Protection

PACKAGE CONTENTS

• Transmitter unit x1 pc
• Receiver unit x 1 pc
• Power supply DCSV/500mA x 2pc
• IR Blaster extension cable x 1pc
• IR receiver extension cable x1 pc
• User 's manual x 1pc

INSTALLATION REQUIREMENTS

1. HDMI source device (computer graphics card, DVD,PS3, HD monitoring equipment etc).
2. HDMI display device like SDTV, HDTV, and projector with HDMI port.
3. Network cables UTP/STP CAT.6/6A/7 cables. Follow the standard EIA-568B. It is recommended to
select a network cable with less loss and crosstalk.
