2.6
Installing the Flexible I/O Module
The IPC50 provides four flexible I/O modules for further expansion needs. The procedure of
installing the flexible I/O module into the system is instructed below.
Step 1
Loosen two screws and remove the blank I/O cover.
Step 2
Find the flexible I/O connector on the main board. Align the flexible I/O module
with the slot, press the card into the connector until it is firmly seated, and
then screw its bracket to the system. Installation is complete.
Hardware Installation
→
IPC950 user's Manual
43
