IPC950 user's Manual
23 No use
25 No use
27 GND
29 No use
31 No use
33 GND
35 No use
37 No use
39 GND
41 SATA1_RXP
43 SATA1_RXN
45 GND
47 SATA1_TXN
49 SATA1_TXP
51 GND
53 No use
55 No use
57 GND
59
61
63
65
67 No use
69 No use
71 GND
73 GND
75 GND
28
24 No use
26 No use
28 No use
30 No use
32 No use
34 No use
36 No use
38 DEVSLP1
40 No use
42 No use
44 No use
46 No use
48 No use
50 No use
52 No use
54 No use
56 No use
58 No use
60 No use
62 No use
64 No use
66 No use
68 No use
70 GND
72 GND
74 GND
