5.7 Dimension Drawings
5.7

Dimension Drawings

Note
All dimensions are in millimeters, unless otherwise stated.
Figure 5.1
Figure 5.2
32
90
Overall Dimensions
38.1
90
Panel Mount Dimensions
162.72
163.12
Installation Manual, 02/2020, C79000-G8976-1387-09
