Siemens SIMATIC NET RUGGEDCOM RSG907R Installation Manual page 12

3
4
5
6
1
2
3
4
5
6
7
8
9
Figure 1.1
POWER LED
ALARM LED
Console Port
Communication Ports
Failsafe Alarm Relay
Power Supply Terminal Blocks
Chassis Ground Terminal
RUGGEDCOM RSG907R
Installation Manual, 02/2020, C79000-G8976-1387-09
1 2
POWER LED
ALARM LED
USB Console Port
RNA Port (Port A/B)
Port 5
Fiber Optic Ethernet Ports (Ports 1 to 4)
Failsafe Alarm Relay
Power Supply Terminal Blocks
Chassis Ground Screw
RUGGEDCOM RSG907R
7
8
9
Illuminates green when power is supplied to the device.
Illuminates red when an alarm condition exists.
The USB Type-B console port is for interfacing directly with the de-
vice and accessing initial management functions. For information
about connecting to the device via the serial console port, refer to
"Connecting to the Device (Page
Communication ports in general receive and transmit data, as well
as provide access to the RUGGEDCOM RUGGEDCOM RSG907R Web
interface. For more information about the various ports available,
refer to "Communication Ports (Page
Latches to default state when a power disruption or other alarm
condition occurs. For more information, refer to:
• "Connecting the Failsafe Alarm Relay (Page 11)"
• "Failsafe Alarm Relay Specifications (Page 30)"
Pluggable terminal blocks for connecting one or more power
sources. For more information, refer to
13)" and "Power Supply Specifications (Page
Protects the device from power surges and accumulated static elec-
tricity. For information about grounding the device, refer to
necting Power (Page 13)".
Introduction
1.2 Description
23)".
25)".
"Connecting Power (Page
29)".
"Con-
3
