8.4 Power cable dimensions (suggested)

Current
1100A
1400A-1600A
1800A
2100A
For UL approval
Current
1100A
1400A - 1600A
1800A
2100A
The directives expressed in the local electrical wiring regulations must be respected in any case.
Supply
Bar type
Bus Bar: 2x 50x6mm
Bus Bar: 2x 50x10mm
Bus Bar: 3x 50x8mm
Bus Bar: 3x 50x10mm
Example 2x Bus Bar
Type
Bus Bars with 4xM8 screws
Screw M
4xM8 Bus Bar: 2x 50x6mm
4xM8 Bus Bar: 2x 50x10mm
4xM8 Bus Bar: 3x 50x8mm
4xM8 Bus Bar: 3x 50x10mm
Connection
Total section of Bus bars
675 mm
1000 mm
1500 mm
1800 mm
29
User's manual
Load
Bar type Screw M
Example 3x Bus Bar
Torque Lb/in (Nm)
2
2
2
2
4xM8
4xM8
4xM8
4xM8
265
(30)
