CD Automation REVO C EXTENDED 2PH User Manual page 32

REVO C
2PH from 1100A to 2100A
8.6.3 Terminal MX 1-2
Terminal Description
1 Internal Connection (G+)
2 Internal Connection (K+)
3 Internal Connection (G-)
4 Internal Connection (K-)
5 Internal Connection (Current Transformer)
6 Internal Connection (Current Transformer)
7 Internal Connection (Fuse fault Switch)
8 Internal Connection (Fuse fault Switch)
9 Internal Connection (Fan fault Switch)
10 Internal Connection (Fan fault Switch)
11 Internal Connection (PT1 Thermal Switch)
12 Internal Connection (PT1 Thermal Switch)
13 PT2 Thermal Switch
14 PT2 Thermal Switch
15 Fan supply voltage (230V standard – 115 option)
16 Fan supply voltage (230V standard – 115 option)
8.6.4 Terminal M6 (Option)
Terminal Description
1 Auxiliary +24Vdc 500mA Input backup power supply for communication
2 GND (0V)
3 Not connected
4 Retransmission Output 0-10Vdc 4-20mA
