Technical Specifications; General Features; Input Features; Output Features 600V - CD Automation REVO C EXTENDED 2PH User Manual

REVO C
2PH from 1100A to 2100A
6

Technical Specifications

6.1 General features

Utilization Category:
IP Code:
Method of Connecting:
Auxiliary voltage:
Order code RC2_ _ _ -_1 = line voltage 100/120V transformer range 90:135V (8 VA Max)
Order code RC2_ _ _ -_2 = line voltage 200/208/220/230/240V transformer range 180:265V (8 VA Max)
Relay output for Heater Break Alarm:
(only with HB option)

6.2 Input features

Digital Input:
Volt Analogic input:
Current Analogic input:
Potentiometer:
Logic input SSR (Fast Enable):

6.3 Output features 600V

Repetitive
Output
peak
Voltage
Current reverse
range
voltage
(Ue)
(Uimp)
(up to
(A) (V)
600V)
1100A 24÷600 1800
1400A 24÷600 1800
1600A 24÷600 1600
1800A 24÷600 1800
2100A 24÷600 1600
AC-51
00 (IP20 on request)
Load in Delta, Load in Star
0.5A a 125VAC
4 ÷ 30Vdc 5mA Max (ON >4Vdc OFF <1Vdc) 0,5Hz max
0 ÷ 10Vdc impedance 15 kΩ
0 ÷ 20mA impedance 100 Ω
4 ÷ 20mA impedance 100 Ω
10 kΩ min.
4 ÷ 30Vdc 5mA Max (ON >4Vdc OFF <1Vdc)
duty cycle min. 100 ms max 3Hz
Latching Max peak Leakage
current one cycle current
(10msec.)
(mAeff) (mAeff)
(A)
700 22400 300
700 22400 300
700 26900 300
700 36000 300
700 38000 300
2
FUSE I T
value
Frequency
Suggested
range
A2s (at
660V)
tp=10msec (Hz)
480.000 47÷70
1.750.000 47÷70
2.200.000 47÷70
2.200.000 47÷70
3.700.000 47÷70
18
User's manual
Power
FANS
loss
(230Vac Standard)
Thyristor
(115Vac Option)
+ Fuse
I=Inom
N° W
(W)
150
2698 2
(75 x 2 Fan)
300
3646 4
(75 x 4 Fan)
300
3722 4
(75 x 4 Fan)
300
4162 4
(75 x 4 Fan)
300
4722 4
(75 x 4 Fan)
m3/h
1560
(780 x 2 Fan)
3120
(780 x 4 Fan)
3120
(780 x 4 Fan)
3120
(780 x 4 Fan)
3120
(780 x 4 Fan)
